MP Filtri - FMM0502BACA10NP01 - Pressure Filter 1/2" 10 UM
MP Filtri - FMM0502BACA10NP01 - Pressure Filter 1/2" 10 UM
MP Filtri - FMM0502BACA10NP01 - Pressure Filter 1/2" 10 UM
MP Filtri - FMM0502BACA10NP01 - Pressure Filter 1/2" 10 UM
MP Filtri - FMM0502BACA10NP01 - Pressure Filter 1/2" 10 UM

In stock - ready to ship

Order now for delivery between 26 May and 29 May
Free shipping

Pay Securely with

MP Filtri - FMM0502BACA10NP01 - Pressure Filter 1/2" 10 UM

MP Filtri - FMM0502BACA10NP01 - Pressure Filter 1/2" 10 UM

€134.12

(Excl. VAT)

Price

(Excl. VAT)

€134.12

Product Description

Suitable for mineral oil Maximum pressure difference across element 20 bar (N series) or 210 bar (S series) Filtering from the outside in Maximum operating pressure 450 bar Burst pressure 1260 bar Temperature -25°C to +110°C Working height is the free space needed under the filter for replacing the element Bypass opening pressure: 6 bar +-10% Flow rate depends on build size and filter choice Filter elements available in Fibreglass (A) or Metal (M) Filter elements available as A03 / A06 / A10 / A16 /A25 / M25 (in µm)
MP Filtri
Mp-filtri produces hydraulic and fuel filtration systems for agricultural and construction machinery. The brand offers filters, separators, and breathers designed to protect engines and hydraulic systems from contamination. Its products are used in tractors, harvesters, and other heavy-duty equipment. Shop more than 628 genuine Mp-filtri spare parts.

Product Details

Brand
MP Filtri
Pros
Can be placed in any position through pipe installation
Unit
Each
Bypass
Yes
Height
195 mm
Length
195 mm
Medium
Hydraulic oil
Includes
Filter comes standard without indicator plug
Sensor port
Yes
Filter finess
10 µm
Max flow rate
85 l/min
Min flow rate
58 l/min
Filtration level
Absolute
Housing material
Steel
Outside diameter
90 mm
Pressure collapse
20 BAR
Filtration material
Glass fibre
Max working pressure
450 BAR
Max working temperature
110 °C
Min working temperature
-25 °C
Inlet port thread diameter
1/2 Inch
Outlet port thread diameter
1/2 Inch
Manufacturer
MP Filtri
