MP Filtri - MPF4003A25H - Return Filter MPF 400/3

SKU: mp-filtri-mpf4003a25h

MP Filtri - MPF4003A25H - Return Filter MPF 400/3

€223.98€191.44 (Excl. VAT)

RRP:€283.50
Save €59.51

In stock - ready to ship

Order now for shipping within 2 to 4 business days

Shipping fee: €11.99 incl. VAT

Pay Securely with

Price

€223.98

Part Number
MPF4003A25H
Package length (mm)
400
Package width (mm)
200
Package height (mm)
200
Unit
Each
Bypass
Yes
Height
290 mm
Length
290 mm
Medium
Hydraulic oil
Filter finess
25 µm
Max flow rate
621 l/min
Technical info
Medium: mineral oil, emulsion and most synthetic oils. Max. working pressure 3 bar. By-pass pressure 1,75 bar.
Filtration level
Absolute
Housing material
Aluminium
Outside diameter
174 mm
Pressure collapse
10 BAR
Filtration material
Glass fibre
Max working pressure
8 BAR
Outlet port diameter
64 mm
Max working temperature
110 °C
Min working temperature
-25 °C
Outlet port thread diameter
2 Inch
Manufacturer

MP Filtri return line filter, part number MPF4003A25H, is designed for hydraulic oil filtration. It features an absolute filtration grade, a bypass function and an aluminum housing. The filter element is made from glass fiber and is suitable for mineral oil, emulsions and most synthetic oils.
MP Filtri
MP Filtri was founded in 1964 in Milan, Italy, and has grown to become a global leader in hydraulic filtration. Headquartered in Pessano con Bornago, Italy, the company remains an independent entity, dedicated to developing innovative solutions for fluid power systems. Its commitment to research and development has positioned it at the forefront of filtration technology. The company specializes in a comprehensive range of hydraulic filters, including pressure filters, return filters, suction filters, and in-line filters. MP Filtri also offers a variety of accessories such as level gauges, filler breathers, and contamination control products. These components are crucial for maintaining the cleanliness and efficiency of hydraulic systems in diverse applications, from industrial machinery to mobile equipment. At Partao, you can find a wide selection of MP Filtri spare parts, including Hydraulic Filters, Air Filters, Bolts & Fasteners, Brackets & Supports, and Engine Gaskets. Equipment operators across various sectors rely on MP Filtri for robust and effective filtration solutions. The brand's products are particularly valued in agricultural and construction machinery for their ability to protect sensitive hydraulic components from wear and contamination, ensuring reliable performance and extended service life in demanding environments. Shop more than 934 genuine MP Filtri spare parts.
