Prillinger Premium - 00133438 - Alternator

SKU: prillinger-premium-00133438

Prillinger Premium - 00133438 - Alternator

€211.92€181.13 (Excl. VAT)

In stock - ready to ship

Order now for shipping within 4 to 6 business days

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€211.92

IMPORTANT NOTE! Before all work on electrical components, these must be de-energized. This means: First disconnect the ground cable (-) of the battery, then disconnect the positive cable (+). The alternator (generator) shaft must always be fixed with a suitable counter-holder (hexagon socket or multi-tooth) and the pulley nut tightened with a torque wrench (do not use an impact wrench). For some pulleys, it is necessary to add shims to properly press the bearing into its seat. Tightening torque: M16 x 1,5 95Nm +/- 5Nm. M27 x 1,5 152Nm +/- 17,5Nm
Prillinger Premium

Brand
Prillinger Premium
Type
2
Angle (°)
R60 °
Current (A)
11
Length (mm)
150
Voltage (V)
14
Length Max (mm)
237
Shaft Diameter 2
17 mm
Connection Thread
M6
Hole Spacing (mm)
151
Outer Diameter (mm)
102.5
Manufacturer
Prillinger Premium
