SKF - 1309K - Bearing
SKF - 1309K - Bearing

Last known price:

€87.92

Get an up-to-date price and availability

Request a Quote

Pay Securely with

SKF - 1309K - Bearing

SKF - 1309K - Bearing

Last known price:

€87.92

Request a Quote

Product Description

The SKF 1309K is a genuine self-aligning ball bearing designed for applications where angular misalignment may occur. It features a 45 mm bore diameter, 100 mm outside diameter, and 25 mm width. This bearing has a 1:12 tapered bore, making it suitable for mounting on tapered shafts or using adapter sleeves. With a basic dynamic load rating of 30.5 kN and a static load rating of 10.8 kN, it provides reliable performance in various industrial and machinery applications.
SKF
SKF is a global supplier of bearings, seals, and lubrication systems for agricultural machinery. The brand provides components for tractors, harvesters, and other farm equipment. Its products are engineered to reduce friction and extend service life in demanding agricultural applications. Shop more than 9,071 genuine Skf spare parts.

Product Details

Brand
skf
Bore Diameter (mm)
45
Outside Diameter (mm)
100
Width (mm)
25
Weight (kg)
0.65
Tapered Bore
1:12
Basic Dynamic Load Rating (kN)
30.5
Basic Static Load Rating (kN)
10.8
Fatigue Load Limit (kN)
0.46
Reference Speed (rpm)
12000
Limiting Speed (rpm)
9000
Minimum Load Factor
0.03
Calculation Factor E
0.35
Calculation Factor Y0
2.1
Calculation Factor Y1
2.1
Calculation Factor Y2
3.2
Chamfer Dimension R Min (mm)
1.5
Abutment Diameter Shaft Da Min (mm)
54
Abutment Diameter Shaft Da Max (mm)
62
Abutment Diameter Housing Da Max (mm)
91
Fillet Radius Ra Max (mm)
1.5
Quality
OEM Supplier
Manufacturer
skf
