SKF - SYK35TR - Y-Bearings SYK 35 TR

OEM Supplier

SKU: skf-syk35tr

SKF - SYK35TR - Y-Bearings SYK 35 TR

€51.28

(excl. VAT)

In stock - ready to ship

Ships within 80 hours
Free shipping on orders over €60

Pay Securely with

Price

(Excl. VAT)

€51.28

The SKF SYK35TR is a high-quality Y-bearing plummer block unit designed for agricultural and industrial applications. Featuring a robust cast iron housing (SY 507 M) and a YAR 207-2F bearing insert, this unit provides reliable performance with a 35 mm bore diameter. It has an overall length of 165 mm, a height of 108 mm, and a width of 48 mm. The unit includes standard contact seals, a grease nipple for lubrication, and is suitable for operating temperatures from -20 to +120 °C. It offers a dynamic load rating of 25.5 kN and a static load rating of 15.3 kN.
SKF
SKF is a global supplier of bearings, seals, and lubrication systems for agricultural machinery. The brand provides components for tractors, harvesters, and other farm equipment. Its products are engineered to reduce friction and extend service life in demanding agricultural applications. Shop more than 9,130 genuine Skf spare parts.

Brand
skf
Part Numbers
syk35tr
Bore Diameter (mm)
35
Housing Material
Cast iron
Bearing Insert Designation
YAR 207-2F
Housing Designation
SY 507 M
Overall Length (mm)
165
Overall Height (mm)
108
Overall Width (mm)
48
Distance Between Bolt Holes (mm)
127
Base Height (mm)
30.2
Bolt Hole Diameter (mm)
14
Weight (kg)
2.1
Dynamic Load Rating (kN)
25.5
Static Load Rating (kN)
15.3
Limiting Speed R (min)
4300
Recommended Tightening Torque (Nm)
6.5
Seal Type
Contact seals
Lubrication
Grease nipple
Operating Temperature Min (°C)
-20
Operating Temperature Max (°C)
120
Quality
OEM Supplier
Manufacturer
skf
