SKF - UCF215 - Y-Bearings UCF 215

OEM Supplier

SKU: skf-ucf215

SKF - UCF215 - Y-Bearings UCF 215

Last known price:

€37.01

Request a Quote

Pay Securely with

Request a Quote

The SKF UCF215 is a high-quality Y-bearing plummer block unit designed for reliable performance in various industrial applications. It features a square flanged housing made of cast iron, ensuring durability and stability. The unit incorporates an insert bearing with a 75 mm bore diameter, equipped with a standard inner ring and grub screw locking for secure shaft attachment. This unit is pre-lubricated and ready for installation, offering excellent resistance to contamination and misalignment.
SKF
SKF is a global supplier of bearings, seals, and lubrication systems for agricultural machinery. The brand provides components for tractors, harvesters, and other farm equipment. Its products are engineered to reduce friction and extend service life in demanding agricultural applications. Shop more than 9,130 genuine Skf spare parts.

Brand
skf
Part Numbers
ucf215
Bore Diameter (mm)
75
Housing Material
cast iron
Bearing Type
Y-bearing plummer block unit
Housing Shape
square flanged
Overall Height (mm)
198
Overall Width (mm)
198
Overall Length (mm)
74.6
Bolt Hole Spacing (mm)
159
Bolt Hole Diameter (mm)
20
Weight (kg)
5.9
Dynamic Load Rating (kN)
52.5
Static Load Rating (kN)
33.5
Quality
OEM Supplier
Manufacturer
skf
