Sparex - S.166338 - Camera System With Monitor 9" 4QUAD
Sparex - S.166338 - Camera System With Monitor 9" 4QUAD
Sparex - S.166338 - Camera System With Monitor 9" 4QUAD
Sparex - S.166338 - Camera System With Monitor 9" 4QUAD
Sparex - S.166338 - Camera System With Monitor 9" 4QUAD
Sparex - S.166338 - Camera System With Monitor 9" 4QUAD

In stock - ready to ship

Order now for delivery between 21 May and 25 May
Free shipping

Pay Securely with

Sparex - S.166338 - Camera System With Monitor 9" 4QUAD

Sparex - S.166338 - Camera System With Monitor 9" 4QUAD

€389.02

(Excl. VAT)

Price

(Excl. VAT)

€389.02

Product Description

This camera system provides a live video feed from up to four cameras to a single 9-inch touchscreen monitor inside the cab. The monitor displays a split-screen or single-camera view, allowing the operator to monitor blind spots around the tractor or implement. Each camera uses a 1/3-inch CMOS sensor with a 120-degree field of view and includes a microphone for audio feedback. The system operates on a 10-to-32-volt DC supply, making it compatible with standard electrical systems on agricultural vehicles. Night vision capability allows the cameras to produce a usable image in low-light conditions. The kit includes the monitor, four cameras, a 20-meter connecting cable, a removable sun visor, and adjustable mounting brackets. On installation, route the cable away from moving driveline components and secure it to prevent chafing.
Sparex

Product Details

Brand
Sparex
Width
236 mm
Height
158 mm
Voltage
10-32V
Resolution
800 (RGB) x 480
Application
Tractors and vehicles
Touchscreen
Yes
Kit Includes
1x 9'' 4QUAD split digital touch button monitor with audio, 1x 1/3 CMOS camera with microphone, 1x 20m 4PIN Cable, 1 x removable sun visor, 2 x adjustable bracket, 1 x User manual
Monitor Size
9"
Night Vision
Yes
Product Type
Camera system
Number Of Cameras
4
Camera Viewing Angle
120°
Manufacturer
Sparex
