Stauff - RS32222P005 - Stauff Pipe Clamp Complete 22x22 mm (5)
Stauff - RS32222P005 - Stauff Pipe Clamp Complete 22x22 mm (5)
Stauff - RS32222P005 - Stauff Pipe Clamp Complete 22x22 mm (5)
Stauff - RS32222P005 - Stauff Pipe Clamp Complete 22x22 mm (5)
Stauff - RS32222P005 - Stauff Pipe Clamp Complete 22x22 mm (5)
Stauff - RS32222P005 - Stauff Pipe Clamp Complete 22x22 mm (5)

In stock - ready to ship

Order now for delivery between 23 May and 27 May
Free shipping on orders over €60

Pay Securely with

Stauff - RS32222P005 - Stauff Pipe Clamp Complete 22x22 mm (5)

Stauff - RS32222P005 - Stauff Pipe Clamp Complete 22x22 mm (5)

€13.10

(Excl. VAT)

Price

(Excl. VAT)

€13.10

Product Description

Application range: Vehicle construction Mechanical engineering Plant engineering Electronics industry Benefits: Long service life Prevents damage and injury Consists of: E
Stauff
Stauff specializes in hydraulic filtration, measurement, and connection systems for agricultural and forestry machinery. Their solutions optimize fluid cleanliness and system efficiency in tractors and implements. The brand is recognized for modular, easy-to-maintain components. Shop more than 515 genuine Stauff spare parts.

Product Details

Brand
STAUFF
Pros
Long service life Prevents damage and injury
Unit
Set
Colour
Black
HHeight
37 mm
Version
Double complete
Diameter
0.866-0.866 Inch
Includes
Each clamp consists of: 2 halves cover plate bottom plate 1 bolt
Material
Polyethylene
Group code
3
Bolt length
45 mm
DIN standard
3015/3
DHoles spacing
36 mm
Product details
Ribbed inner surface with pre-tensioning Good UV resistance Rounded edges Material: Polypropylene P001: 1 clamp P005: 5 clamps P025: 25 clamps
Long description
Application range: Vehicle construction Mechanical engineering Plant engineering Electronics industry Benefits: Long service life Prevents damage and injury Consists of: E
Content in sale unit
5 pcs
Mounting plate width
70 mm
Max. working temperature
90 °C
Min. working temperature
-30 °C
Mounting thread diameter
M8
Mounting hole diameter (width)
9 mm
Manufacturer
STAUFF
