Stoll - 1403310 - Joystick Universal Joint Cross

This universal joint cross sits at the pivot point of the joystick assembly, transmitting angular motion from the control lever to the hydraulic spool or linkage it actuates. It is the component that allows the joystick to move in multiple axes while maintaining a rigid mechanical connection. Wear in the cross bearings introduces play, which results in imprecise control response and delayed or jerky hydraulic valve movement. As an original part from the manufacturer, the cross is machined to the same pivot-pin bore tolerance and thread specification as the joystick housing it was designed for, so no shimming or bushing adaptation is needed during replacement. On installation, ensure the retaining circlips or bolts are fully seated and the cross moves freely through its full range of motion before securing the assembly.
