Sunfab - SCM047WPSC4C14V2M - Piston Motor 47cc C14 V2
Sunfab - SCM047WPSC4C14V2M - Piston Motor 47cc C14 V2

In stock - ready to ship

Order now for delivery between 23 May and 27 May
Free shipping

Pay Securely with

Sunfab - SCM047WPSC4C14V2M - Piston Motor 47cc C14 V2

Sunfab - SCM047WPSC4C14V2M - Piston Motor 47cc C14 V2

€1,386.11

(Excl. VAT)

Price

(Excl. VAT)

€1,386.11

Product Details

Brand
Sunfab
Unit
Each
Weight
15 kg
Benefits
High shaft load capacity Very high operating pressure
Properties
Axial piston motor Fixed capacity Very reliable Robust Reversible
Shaft type
C14-14T 12/24
Seal material
H
N max. (R.P.M)
5300 r/min
N min. (R.P.M)
300 r/min
Technical info
Use engine's top leakage oil connection Fill with oil before commissioning Use high performance oil in accordance with ISO type HM, DIN 51524-2HLP or better Oil temperature with nitrile seal: max. 75°C Oil temperature with Viton seal: max. 90°C
Application range
High starting torque applications High speed applications Mobile hydraulics
Crash turn moment
0,75 N·m
Continuous pressure
350 BAR
Continuous power max.
65 kW
Max. Power (kW) cont.
52 kW
Max. revolutions (Rpm)
5300
N max. (R.P.M) interm.
5900 r/min
SAE size of rear cover
V2
Max. Power (kW) interm.
135 kW
Stroke volume (cm³/rev)
47.1 cm³/rev
Intermittent pressure max.
400 BAR
Max. revolutions intermittend
5900 r/min
Pressure continuous operation
350 BAR
Pressure intermittend operation
400 BAR
Manufacturer
Sunfab
