Supreme - AZ99132 - Elbow 32mm PExPE
Supreme - AZ99132 - Elbow 32mm PExPE

In stock - ready to ship

Order now for delivery between 18 May and 21 May
Free shipping on orders over €60

Pay Securely with

Supreme - AZ99132 - Elbow 32mm PExPE

Supreme - AZ99132 - Elbow 32mm PExPE

€5.18

(Excl. VAT)

Price

(Excl. VAT)

€5.18

Product Description

Application: Non drinking water supply, pipe connection in gardening, agriculture and horticulture irrigation. Materials: Top quality raw materials which makes S10 fittings highly resistant and reliable in time. Body, nut, thrust ring: virgin polypropylene (PP-B), high mechanical and UV resistant with thermal stability. Grip ring: copolymer polyacetal resin (POM), white color. Conical gasket: rubber NBR or EPDM, hardness 70sh, black color Reinforcement ring: only for female threads >=1 ½ “, stainless steel Working temperature: -10/+45 °C Maximum working pressure: 10 bar
Supreme
Supreme manufactures agricultural machinery and tractor attachments for soil preparation and crop maintenance. The brand specializes in durable tillage equipment, including plows and cultivators, designed for heavy-duty farming operations. Its products are known for robust construction and compatibility with various tractor models. Shop more than 282 genuine Supreme spare parts.

Product Details

Brand
Supreme
Pros
By tightening the nut – Special Conical gasket – is also moving radially and increasing its compression towards the pipe wall so it balancing pipe defects such as undersize, ovalization and little scratches. Easy and fast assembly without any particular preparation of the pipe.
Unit
Each
Angle
90 °
Shape
Elbow - 2 connection sides
Colour
Green
Material
PVC-U
Pipe diameter
32 mm
Connection 2, type
PE Compression fittings
Connection no 1 type
PE Compression fittings
Connection 2, diameter
32 mm
Connection no 1 diameter
32 mm
Connection 2, type - male/female
Female
Connection no 1 type - male/female
Female
Manufacturer
Supreme
