Voss - RSWS16SM22WD - Angled Banjo Coupling

Voss - RSWS16SM22WD - Angled Banjo Coupling

Voss - RSWS16SM22WD - Angled Banjo Coupling

Voss - RSWS16SM22WD - Angled Banjo Coupling

Voss - RSWS16SM22WD - Angled Banjo Coupling

Voss - RSWS16SM22WD - Angled Banjo Coupling

Number of products

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Free shipping on orders over €60

Pay Securely with

Voss - RSWS16SM22WD - Angled Banjo Coupling

Voss - RSWS16SM22WD - Angled Banjo Coupling

€14.88

(Excl. VAT)

Price

(Excl. VAT)

€14.88

Number of products

Voss

Voss is a supplier of industrial and agricultural components, including hydraulic systems and fittings. The brand's products are used in tractor attachments, irrigation systems, and other farm machinery requiring reliable fluid handling. Its solutions ensure high performance and durability in demanding agricultural applications. Shop more than 2,632 genuine Voss spare parts.

Product Details

Brand

Unit

Each

Angle

90 °

Shape

Elbow - 2 connection sides

Series

LL L S

DIN standard

2353 228 3852 2401

ISO standard

228

Pipe diameter

16 mm

Seal material

Metal Synthetic elastomer

Inside diameter

11 mm12 mm

Surface treatment

Zinc Nickel

Connection 2, type

Cutting ring

Connection 2, length

43 mm

Connection no 1 type

Banjo

Max working pressure

400 BAR

Connection 2, diameter

16 mm

Max. tightening torque

140 N·m

Connection no 1 hex size

27,9 mm

Connection 2, thread type

Metric

Connection 2, wrench size

30.0 mm

Connection 2, thread pitch

1.50 mm

Connection no 1 thread type

Metric

Connection no 1 thread pitch

1.50 mm

Connection 2, thread diameter

M24

S2Connection no 1 wrench size

27.0 mm

Connection no 1 thread diameter

22 mm

L1Connection no 1 thread length

14 mm

Connection 2, type - male/female

Male

Connection no 1 type - male/female

Male

Connection 2, centre to end distance

21,5 mm

Connection no 1 center to end distance

30 mm

Manufacturer

Voss
