Wabco - 4700152690 - Wabco Trailer Control Valve - 4057875216797

OEM Supplier

SKU: wabco-4700152690

Wabco - 4700152690 - Wabco Trailer Control Valve - 4057875216797

€1,442.31€1,232.74 (Excl. VAT)

In stock - ready to ship

Order now for shipping within 2 to 4 business days

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€1,442.31

Brand
Wabco
Part Numbers
4057875216797; 4700152690; 8284700152690; 470 015 269 0
OEM Part Numbers

Wabco

Type
douple circiut
Unit
Each
Mounting
9 mm
Properties
Max. operating pressure (pneumatic part): 10 bar Max. operating pressure (hydraulic part): 120 bar Temperature range: -40 °C > +80 °C
Holes spacing
26.0 mm
Intended medium
Oil
Long description
Application: Control valves for dual-pipe trailer brake systems Controlling the dual-pipe trailer brake system in combination with the hydraulic main brake cylinder or the hydraulic sensor of the agricultural tractor Properties: Max. operating pressure (pneumatic part): 10 bar Max. operating pressure (hydraulic part): 120 bar Temperature range: -40 °C > +80 °C
Adsorption volume
2 cm³
Application range
Control valves for dual-pipe trailer brake systems Controlling the dual-pipe trailer brake system in combination with the hydraulic main brake cylinder or the hydraulic sensor of the agricultural tractor
Actuation pressure
1 BAR
Max working pressure
8,5 BAR
Connection thread pitch
1.50 mm
Max working temperature
80 °C
Min working temperature
-40 °C
Connection 2, thread pitch
1.00 mm
Connection thread diameter
M16
Connection 2, thread diameter
M10
Hydraulic part limit pressure
14 BAR
EAN
4057875216797
Manufacturer
Wabco

Application: Control valves for dual-pipe trailer brake systems Controlling the dual-pipe trailer brake system in combination with the hydraulic main brake cylinder or the hydraulic sensor of the agricultural tractor Properties: Max. operating pressure (pneumatic part): 10 bar Max. operating pressure (hydraulic part): 120 bar Temperature range: -40 °C > +80 °C
Wabco
Wabco is a leading supplier of braking and stability control systems for agricultural trailers and machinery. The brand focuses on safety and performance in heavy-duty transport applications. Its technologies enhance efficiency and reliability in farming logistics. Shop more than 1,368 genuine Wabco spare parts.
