Walterscheid - W2100860 - Adapter SD05

€350.04

(Excl. VAT)

Price

(Excl. VAT)

€350.04

Number of products

Product Description

The Walterscheid W2100860 is a genuine SD05 adapter designed for various agricultural and industrial applications. This essential component ensures proper connection and functionality within power take-off (PTO) systems. Manufactured by Walterscheid, it guarantees reliable performance and durability.

Walterscheid is a leading manufacturer of driveline components and power transmission systems for agricultural machinery. The brand produces PTO shafts, couplings, and gearboxes for tractors and implements. Its solutions are engineered for high torque and durability in demanding farming applications. Shop more than 5,365 genuine Walterscheid spare parts.

Product Details

Brand

Walterscheid

Part Numbers

w2100860

Unit

Each

Length

860 mm

Size code

W2100

Properties

Tension side 1-3/8" (6) shaft collar kit Machine side 1-3/8" (6) slide pin Lubrication frequency from 50 to 100 hours Fulfilling the requirements laid out in EC 89/392 EEC Fulfilling the safety standard EN12965 CE marking available

Consists of

PTO shaft with shielding Declaration of conformity Instruction manual

Power 540 rpm

12 kW

Power 1000 rpm

18 kW

Technical info

See Walterscheid instruction manual Max. dynamic capacity 540 rpm: 12 kW, 210 Nm Max. dynamic capacity 1000 rpm: 18 kW, 175 Nm Values at working angle 5° and service life 1000 hours LZ = slid in length in mm, from intersection to intersection

Protection type

SD05

Long description

PTO drive shafts complete standard series W 2100

Application range

Small crop sprayers Tedders Windrowers

Max static torque

1150 N·m

Inner tube profile

OOcH

Outer tube profile

Profile tube shape

Lemon

Attachment machine side

Quick disconnect yoke

Attachment tractor side

Quick disconnect yoke

Inner tube wall thickness

3,4 mm

Outer tube wall thickness

2,8 mm

Locking type by machine side

Collar lock

Locking type by tractor side

Collar lock

Inner tube large outside diameter

31 mm

Outer tube large outside diameter

39 mm

Cross joint length by machine side

55 mm

Cross joint length by tractor side

55 mm

Cross joint bush diameter by machine side

22 mm

Cross joint bush diameter by tractor side

22 mm

Connection outside diameter by machine side

1-3/8 Inch

Connection outside diameter by tractor side

1-3/8 Inch

Connection number of splines/grooves by machine side

Connection number of splines/grooves by tractor side

EAN

8435194030595

Manufacturer

Walterscheid
