Walvoil - VBPDL05001 - CONTROLLED CHECK VALVE 3/8

OEM Quality

SKU: walvoil-vbpdl05001

Walvoil - VBPDL05001 - CONTROLLED CHECK VALVE 3/8

€67.64

(excl. VAT)

In stock - ready to ship

Ships within 48 hours
Free shipping

Pay Securely with

Price

(Excl. VAT)

€67.64

This double-acting controlled check valve consists of two controlled check valves. Activation takes place internally from the opposite pressure line. For example, a double-acting cylinder can be secured against unintentional lowering in both directions. The valve should be mounted as close to the user as possible. Show more
Walvoil
Walvoil designs and manufactures hydraulic components and systems for agricultural and industrial machinery. The brand specializes in valves, pumps, and steering units for tractors and off-road equipment. Its products ensure precise fluid control and reliability in heavy-duty farming operations. Shop more than 1,006 genuine Walvoil spare parts.

Brand
Walvoil
Part Numbers
vbpdl05001
Type
Double
Unit
Each
Material
Aluminium
Pilot ratio
1:4.0
ATotal width
110 mm
BTotal height
50 mm
FTotal length
170 mm
Max flow rate
35 l/min
Intended medium
Mineral oil
Long description
This double-acting controlled check valve consists of two controlled check valves. Activation takes place internally from the opposite pressure line. For example, a double-acting cylinder can be secured against unintentional lowering in both directions. The valve should be mounted as close to the user as possible. Show more
Opening pressure
0,5 BAR
Max working pressure
210 BAR
Number of connections
4
Connections thread type
BSP
Connections thread diameter
3/8 Inch
Manufacturer
Walvoil
