Home
Attachments & Lift
Hydraulic Systems
Hydraulic Control Valves
Walvoil - VBPDL05002ST - Pilot Check Valve VBPDL 05 A06
Walvoil - VBPDL05002ST - Pilot Check Valve VBPDL 05 A06
Walvoil - VBPDL05002ST - Pilot Check Valve VBPDL 05 A06
Walvoil - VBPDL05002ST - Pilot Check Valve VBPDL 05 A06
Walvoil - VBPDL05002ST - Pilot Check Valve VBPDL 05 A06
Walvoil - VBPDL05002ST - Pilot Check Valve VBPDL 05 A06

In stock - ready to ship

Order now for delivery between 23 May and 27 May
Free shipping

Pay Securely with

Walvoil - VBPDL05002ST - Pilot Check Valve VBPDL 05 A06

Walvoil - VBPDL05002ST - Pilot Check Valve VBPDL 05 A06

€76.51

(Excl. VAT)

Price

(Excl. VAT)

€76.51

Product Description

This double-acting controlled check valve consists of two controlled check valves. Activation takes place internally from the opposite pressure line. For example, a double-acting cylinder can be secured against unintentional lowering in both directions. The valve should be mounted as close to the user as possible. Show more
Walvoil
Walvoil designs and manufactures hydraulic components and systems for agricultural and industrial machinery. The brand specializes in valves, pumps, and steering units for tractors and off-road equipment. Its products ensure precise fluid control and reliability in heavy-duty farming operations. Shop more than 1,006 genuine Walvoil spare parts.

Product Details

Brand
Walvoil
Type
Double
Unit
Each
Material
Steel
Pilot ratio
1:4.0
ATotal width
110 mm
BTotal height
50 mm
FTotal length
170 mm
Max flow rate
35 l/min
Intended medium
Mineral oil
Opening pressure
0,5 BAR
Max working pressure
350 BAR
Number of connections
4
Connections thread type
BSP
Connections thread diameter
3/8 Inch
Manufacturer
Walvoil
