Walvoil - VMPBL10001ST - Pressure Control Valve
Walvoil - VMPBL10001ST - Pressure Control Valve
Walvoil - VMPBL10001ST - Pressure Control Valve
Walvoil - VMPBL10001ST - Pressure Control Valve
Walvoil - VMPBL10001ST - Pressure Control Valve
Walvoil - VMPBL10001ST - Pressure Control Valve
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping

Pay Securely with

Walvoil - VMPBL10001ST - Pressure Control Valve

Walvoil - VMPBL10001ST - Pressure Control Valve

€75.13

(Excl. VAT)

Price

(Excl. VAT)

€75.13

Product Description

The Walvoil VMPBL10001ST is a genuine direct-acting pressure relief valve designed for hydraulic systems. It features an adjustable pressure range of 10 to 100 bar (145 to 1450 psi) and supports a maximum flow rate of 60 L/min. Constructed with a durable steel body and NBR (Buna-N) seals, this valve ensures reliable performance up to a maximum system pressure of 350 bar (5075 psi). It is equipped with G 3/8" BSP ports for easy integration into various hydraulic circuits.
Walvoil
Walvoil designs and manufactures hydraulic components and systems for agricultural and industrial machinery. The brand specializes in valves, pumps, and steering units for tractors and off-road equipment. Its products ensure precise fluid control and reliability in heavy-duty farming operations. Shop more than 1,006 genuine Walvoil spare parts.

Product Details

Brand
Walvoil
Type
Spring-loaded valve
Unit
Each
Properties
Type: spring-loaded valve, direct control Opens from P to T Intermittent fast-reacting circuit
HTotal height
147 mm
CHousing width
35 mm
Max. flow rate
60 l/min
AHousing length
78 mm
Adjustment type
Socket screw
Connection type
Thread
Housing material
Steel
Application range
For installation between lines High pressure and moderate to high volume flow For use as a pump safety device
Max working pressure
350 BAR
Connection thread type
BSP
ZMounting holes diameter
6,5 mm
Adjustable pressure range
180-350 BAR
Connection thread diameter
1/2 Inch
Manufacturer
Walvoil
