WEY - DN080VNAN - Knife Valve + Handwheel DN80

WEY - DN080VNAN - Knife Valve + Handwheel DN80

WEY - DN080VNAN - Knife Valve + Handwheel DN80

WEY - DN080VNAN - Knife Valve + Handwheel DN80

Number of products

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Free shipping

Pay Securely with

WEY - DN080VNAN - Knife Valve + Handwheel DN80

WEY - DN080VNAN - Knife Valve + Handwheel DN80

€394.93

(Excl. VAT)

Price

(Excl. VAT)

€394.93

Number of products

Product Description

Connection flange valve with handwheel control Pipe boot sealed by sealing on the narrow side of the plate Adjustable transverse seal prevents medium from leaking externally Blade-shaped valve plate shears off solid objects No deposits thanks to scraper strips and special plate geometry

Wey

Product Details

Brand

Unit

Each

Benefits

100% waterproof Long service life High level of operational reliability

Properties

Material from housing: GG25 with epoxy plastic coating EKB Upper construction: stainless steel with epoxy plastic coating EKB Plate: stainless steel 1.4404 Spindle/piston rod: stainless steel 1.4404 Seal: EPDM Temperature range: -20 to +130°C

Technical info

Flanged hole: PN 10/16 - tested according to EN 1092/ISO 7005 Length: EN 558-1/ISO 5752 Series 20 Other designs can be supplied upon request

Application range

Biogas plants: food scraps, manure, renewables (renewable raw materials) etc. Wastewater treatment plants: untreated wastewater, raw sludge, faecal matter etc. Sugar industry: beet washing plant etc. Food industry: conveyors for cereals, vegetables etc. Pulp and paper industry

BLFlange thickness

46 mm

Max working pressure

10 BAR

DHHand wheel diameter

200 mm

Type of drive/steering

Hand wheel

DFlange outside diameter

200 mm

DNPassage hole nominal diameter

80 mm

KFlange mounting bolts/holes distance

160 mm

HPassage hole centre to lever end distance

358 mm

ØFlange mounting bolts/holes thread diameter

M16

Manufacturer

WEY
