White - OMPX25011186710 - Orbit Motor Black
White - OMPX25011186710 - Orbit Motor Black
White - OMPX25011186710 - Orbit Motor Black
White - OMPX25011186710 - Orbit Motor Black
White - OMPX25011186710 - Orbit Motor Black
White - OMPX25011186710 - Orbit Motor Black

In stock - ready to ship

Order now for delivery between 18 May and 21 May
Free shipping

Pay Securely with

White - OMPX25011186710 - Orbit Motor Black

White - OMPX25011186710 - Orbit Motor Black

€304.71

(Excl. VAT)

Price

(Excl. VAT)

€304.71

Product Details

Brand
White
Unit
Each
Benefits
Flexible
Max. power
8,4 kW
Properties
Robust and compact construction High axial and radial load carrying capacity of the axle High starting torque Pressure drop: P1 = operating pressure continuous, P2 = operating pressure intermittent
Shaft type
Cylindrical
Flange code
A2
Displacement
250 cm³/rev
Flange shape
Oval
Sealing type
High pressure
Port position
Side
Housing length
159,2 mm
Max. flow rate
60 l/min
Shaft diameter
25 mm
Technical info
Orbital motor offers compact construction and simple mounting. High torque and shaft load, because of shorter distance from mounting flange to the point of load application.
Flange diameter
82,5 mm
Application range
Wherever high torque and low speeds are required, e.g. for sweeping brushes, loader wagons, chain drives, spreaders, lawnmowers, winches, agricultural machinery, forestry machinery and construction machinery
Max rotation speed
250 r/min
Min. starting torque
375 N·m
Main port thread type
G
Max continuous torque
400 N·m
Drain port thread type
G
Min. starting pressure
5 BAR
Number of mounting holes
2
Main port thread diameter
1/2 Inch
Drain port thread diameter
1/4 Inch
Mounting holes circle diameter
106,4 mm
Max. continous working pressure
120 BAR
Max intermittend working pressure
155 BAR
Manufacturer
White
