Danfoss - OMTS160151B3036 - Orbit Motor Short

OEM Supplier

SKU: danfoss-omts160151b3036

Danfoss - OMTS160151B3036 - Orbit Motor Short

€807.59

(excl. VAT)
RRP:€1,167.25
Save €359.63
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping

Pay Securely with

Price

(Excl. VAT)

€807.59

Danfoss
Danfoss A/S is a global leader in climate and energy-efficient solutions, founded in 1933 by Mads Clausen on his parents' farm in Nordborg, Denmark. The company began with the invention of the expansion valve for refrigeration systems and has since grown into a multinational corporation. Headquartered in Nordborg, Denmark, Danfoss remains a privately held company, known for its innovative approach to engineering and sustainable technologies. Danfoss offers a broad portfolio of products across various segments, including heating, cooling, power solutions, and drives. In the agricultural sector, its hydraulic and electronic control systems are vital components for modern machinery. The brand is recognized for its advanced hydrostatic transmissions, such as the H1 series, and its comprehensive range of hydraulic pumps, motors, valves, and steering components, which enhance precision and efficiency in tractors, harvesters, and other heavy equipment. Partao provides a wide selection of genuine Danfoss spare parts, including Seal Kits, Air Filters, Ball Bearings, Bearing Housings, and Bolts & Fasteners. Over 11,238 genuine Danfoss spare parts are available at Partao. Agricultural professionals worldwide choose Danfoss components for their robust construction, advanced control capabilities, and contribution to operational efficiency. The brand's commitment to developing intelligent and energy-saving solutions helps farmers and operators optimize their machinery's performance, reduce fuel consumption, and achieve greater productivity in demanding field conditions.

Brand
Unit
Each
Max. power
26,5 kW
Shaft type
Straight parallel
Displacement
160 cm³/rev
Flange shape
Short
L1Rotor length
16,5 mm
Max. flow rate
100 l/min
Shaft diameter
37,6 mm
Technical info
Orbital motor offers compact construction and simple mounting. High torque and shaft load, because of shorter distance from mounting flange to the point of load application.
LHousing length
146 mm
Application range
In combination with gearboxes, e.g., as a wheel drive
Max pressure peak
280 BAR
Max rotation speed
625 r/min
Min rotation speed
10 r/min
Main port thread type
G
Max continuous torque
470 N·m
Shaft number of teeth
16
Drain port thread type
G
Number of mounting holes
4
Main port thread diameter
3/4 Inch
Drain port thread diameter
1/4 Inch
Max. continous working pressure
200 BAR
Max intermittend working pressure
240 BAR
Manufacturer
Danfoss
