ELBE - EDS52020100 - Double Cross Coupling

SKU: elbe-eds52020100

ELBE - EDS52020100 - Double Cross Coupling

Last known price:

€59.11

Request a Quote

Pay Securely with

Request a Quote

Brand
elbe
Part Numbers
eds52020100
Type
EDS
Bearing Type
plain bearing
Length (mm)
100
Outer Diameter (mm)
52
Bore Diameter (mm)
20
Bore Type
smooth
Max Operating Angle (°)
35
Max Speed (rpm)
1000
Max Torque (Nm)
1000
Weight (kg)
1.1
Manufacturer
elbe

The ELBE EDS52020100 is a genuine double cross coupling from the EDS series, featuring a robust plain bearing design. Engineered for demanding applications in agricultural machinery, construction equipment, municipal vehicles, and other special vehicles. This coupling has an outer diameter of 52mm, a bore diameter of 20mm, and an overall length of 100mm. It is designed to handle a maximum operating angle of 35 degrees and a maximum speed of 1000 rpm, with a maximum torque capacity of 1000 Nm. Weighing 1.1 kg, it ensures reliable power transmission.
Elbe
Elbe produces agricultural machinery components, including gearboxes and drivetrain parts. The brand supplies spare parts for tractors and implements used in farming operations. Its components are engineered for precision and long service life. Shop more than 32 genuine Elbe spare parts.
