Faster - ANV14GASF - Quick Coupling
Faster - ANV14GASF - Quick Coupling
Faster - ANV14GASF - Quick Coupling
Faster - ANV14GASF - Quick Coupling

In stock - ready to ship

Order now for delivery between 18 May and 21 May
Free shipping on orders over €60

Pay Securely with

Faster - ANV14GASF - Quick Coupling

Faster - ANV14GASF - Quick Coupling

€7.62

(Excl. VAT)

Price

(Excl. VAT)

€7.62

Product Description

The Faster ANV14GASF is a high-quality male quick coupling designed for hydraulic systems, featuring a 1/4" BSP thread and a flat face design for minimal fluid loss and air inclusion. This coupling is equipped with a poppet valve for reliable sealing and is suitable for various agricultural and industrial applications requiring quick and secure hydraulic connections. It ensures efficient fluid transfer and robust performance under demanding conditions.
Faster
Faster produces agricultural machinery, including tillage equipment and tractor-mounted implements. The brand focuses on robust designs for heavy-duty farming tasks such as plowing and seeding. Its products are widely used in European agriculture for their reliability and performance. Shop more than 1,003 genuine Faster spare parts.

Product Details

Brand
Faster
Unit
Each
Shape
Straight - 2 connection sides
Length
48 mm
Series
ANV
Weight
84,9 g
Details
Simple coupling with very light spring in coupling sleeve Large number of latching balls
Benefits
User-friendly Reduces brinelling
Material
Carbon steel
Body size
6,3 mm
Size code
BG 1
Properties
Axial actuation of locking sleeve to rear (single acting) Induction hardened stressed parts No breakaway function
Valve type
Poppet
ISO standard
7241-1-A
Total length
1,86 Inch
Seal material
Nitrile rubber [NBR] Teflon (PTFE)
L1Total length
72 mm
Outside diameter
25 mm
Working pressure
500 BAR
Application range
For universal use Agricultural machines Municipal services technology Viniculture Mineral oil-based fluids
Surface treatment
White passivated
Connection 2, type
Thread
Flow rate at 2 bar
8 l/min
Connection no 1 type
Quick coupling
Max working temperature
125 °C
Connection no 1 diameter
25 mm
Connection no 1 hex size
0,75 Inch
Min. working temperature
-25 °C
Connection 2, thread type
BSPP
XConnection no 1 hex size
19 mm
Connectable under pressure
No
Connection no 1 thread type
BSP
Connection 2, thread diameter
1/4 Inch
Quick connection locking type
Radial balls
Quick connection working type
Sleeve retraction
Connection 2, threads per inch
19
Connection no 1 thread diameter
1/4 Inch
Connection 2, type - male/female
Female
Quick disconnection working type
Sleeve retraction
Connection no 1 type - male/female
Female
Manufacturer
Faster
