Permission
c UL us - Listed (OL)
Control Output
2x PNP or 2x NPN adjustable
Fastening Type
Insertable from above into the slot
Line Properties
energiekettentauglich/ robotertauglich
Setting Options
kapazitive Taste
Housing Material
High-alloyed stainless steels
IO-Link, Profile
Smart sensor profile
Certification Body
UL E232949
Measured Parameter
Position
Overload Resistant
Available
Recording Range (mm)
52000
Test Conditions Line
Energiekette: > 5 Millionen Zyklen, Biegeradius 28 mm
Cable Sleeve Material
TPE-U(PUR)
Installation Position
arbitrary
Measurement Principle
Hall magnetic
LABS (PWIS) Conformity
VDMA24364-B2-L
Resolution Travel (mm)
0,02
Max. Output Current (mA)
50
Short Circuit Resistance
yes
Ambient Temperature (°C)
-40 to 80
IO-Link, Function Classes
Schalt Signal Kanal (SSC)
IO-Link, Protocol Version
Device V 1.1
IO-Link, SIO Mode Support
yes
Max. Movement Speed (m/s)
3
Switching Element Function
Opener/closer switchable
Switching Status Indicator
LED yellow
Connection Outlet Direction
along
IO-Link, Communication Mode
COM2 (38.4 kBaud)
Reverse Polarity Protection
for all electrical connections
Sampling Interval Type (ms)
2
Typical Linearity Error (mm)
±1
Max. Switching Frequency (Hz)
125
IO-Link, Process Data Width IN
2 Bytes
Max. Switch Off Voltage DC (V)
30
Max. Switching Capacity DC (W)
1,5
Operating Voltage Range DC (V)
10 to 30
IO-Link, Minimum Cycle Time (ms)
2,5
IO-Link, Process Data Contents IN
4 bit SSC (Switching Signal)
Electrical Connection 1, Connection Type
cable
UKCA Marking (See Declaration Of Conformity)
nach UK RoHS Vorschriften
CE Certificate (See Declaration Of Conformity)
nach EU-RoHS-Richtlinie
Electrical Connection 1, Connection Technology
Open end
Electrical Connection 1, Number Of Pins / Wires
4
Suitability For The Production Of Li-ion Batteries
Geeignet für Batterieproduktion mit reduzierten Cu/Zn/Ni Werten (F1a)
Ambient Temperature For Moving Cable Placements (°C)
-20 to 70
Cleanroom Suitability, Measured According To ISO 14644-14
Klasse 4 nach ISO 14644-1
