Festo - 8152245 - Vacuum Suction Nozzle

SKU: festo-8152245

Festo - 8152245 - Vacuum Suction Nozzle

€321.24€274.56 (Excl. VAT)

In stock - ready to ship

Order now for shipping within 4 to 6 business days

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€321.24

Brand
Festo
KC-mark
KC-EMV
Permission
c UL us - Listed (OL)
Max. Vacuum
92
Material Note
RoHs compliant
Power-on Time
100%
Fastening Type
With throughway bores
Seals Material
NBR
Valve Function
closed
Analogue Output
0 - 10 V
Filter Material
POM
Filter Porosity
40
Line Properties
energiekettentauglich
Screws Material
Steel
Cable Length (m)
2,5
Housing Material
PA reinforced
Operating Medium
Compressed air to ISO 8573-1:2010 [7:4:4]
Silencer Material
PE
Vacuum Connection
für Schlauch Außen-Ø 6 mm
Cable Diameter (mm)
2,9
Cable Shield Colour
Grey
Construction Set Up
T-shape
Integrated Function
Silencer open
Jet Nozzle Material
Aluminium wrought alloy
Measurement Process
Piezoresistive pressure sensor
Protection Category
IP40
Pitch Dimension (mm)
15
Cable Sleeve Material
PVC
Hand Assist Actuation
tentative
Installation Position
arbitrary
Ejector Characteristic
Standard
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Pneumatic Connection 1
für Schlauch Außen-Ø 6 mm
Pneumatic Connection 3
Silencer open
Capture Nozzle Material
POM
Medium Temperature (°C)
0 to 50
Operating Pressure (MPa)
0,2 to 0,7
Tolerance Cable Diameter
± 0,1 mm
Ambient Temperature (°C)
0 to 50
Coil Characteristic Value
24 V DC: 1,28 W
Regulation Screw Material
Steel
Connection Thread Material
POM
Corrosion Resistance Class KBK
2 - moderate corrosion stress
Operating Voltage Range DC (V)
21.6 to 26.4
Construction Type Silencer Type
open
Nominal Width Laval Nozzle (mm)
0,95
Nominal Operating Pressure (MPa)
0,4
Pressure Measurement Range (MPa)
-0,1 to 0
Conductor - Nominal Cross-section
0,14
Note On Operating And Control Medium
Oiled operation not possible
Operating Voltage Range DC Sensor (V)
18 to 30
Electrical Connection: Input, Function
Vakuumerzeugung
Electrical Connection: Outlet, Function
sensor
Operating Pressure For Max. Vacuum (MPa)
0,38
Electrical Connection: Inlet, Fastening Type
Ratcheting lock
UKCA Marking (See Declaration Of Conformity)
nach UK Vorschriften für EMV
Electrical Connection: Input, Connection Type
2x plug
CE Certificate (See Declaration Of Conformity)
to EU EMC directive
Electrical Connection: Outlet, Connection Type
cable
Max. Suction Volume Flow Rate Against Atmosphere
21
Noise Level For Nominal Operating Pressure (dB(A))
68
Electrical Connection: Input, Connection Technology
M8x1 A coded to EN 61076-2-104
Electrical Connection: Input, Number Of Pins / Wires
2
Electrical Connection: Outlet, Connection Technology
Open end
Electrical Connection: Outlet, Number Of Pins / Wires
3
Operating Pressure For Max. Suction Volume Flow (MPa)
0,4
Air Supply Time At Nominal Operating Pressure With Ejector Pulse (s)
1
EAN
4052568639167
Manufacturer
Festo
