Festo - CECC-S-574416 - Control

SKU: festo-cecc-s-574416

Browse all parts
Festo - CECC-S-574416 - Control

€1,211.72€1,035.66 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€1,211.72

Brand
Festo
Report
CANopen, I-port, IO-Link, Modbus TCP
CPU Data
Processor 400 MHz
Permission
RCM mark, c UL us - Listed (OL)
Power Input
100 mA nominal bei 24 V DC
USB Interface
USB 1.1
IO-Link, Report
Device V 1.0, Master V 1.1
Status Displays
LED
Ethernet, Number
1
IO Link, Storage
2 kByte / port
Max. Line Length
30 m Eingänge
Protection Class
III
Operating Voltage
20,4 - 30 V DC
Relative Humidity
95 %, Not condensing
Certification Body
UL E239998-D1001
Fieldbus Interface
CAN bus
IO-Link, Port Type
Device A, Master B
Protection Category
IP20
Material Information
RoHs compliant
Programming Language
Instruction list (AWL), Contact diagram (KOP), acc. to IEC 61131-3, Sequence language, Function plan, Structured text
Programming Software
CODESYS provided by Festo V3
Max. Power Supply (A)
6,0
IO-Link, Communication
C/Q LED green, C/Q LED red
Serial Interface, Type
2 x RS232 / 1 x RS 485-A/422-A
Quantity Digital Inputs
12
Digital Outputs, Contact
Transistor
Encoder Inputs, Quantity
1
IO-Link, Number Of Ports
Device 1, Master 1
Quantity Digital Outputs
8
Ambient Temperature (°C)
0 to 55
Bearing Temperature (°C)
-25 to 70
Ethernet, Connection Plug
RJ45
Encoder Inputs, Resolution
32 Bit
Serial Interface, Quantity
3
IO-Link, Communication Mode
configurable using software, Device COM1 (4.8 kBaud), COM2 (38.4 kBaud), COM3 (230.4 kBaud), Master SIO, COM1 (4.8 kBaud), COM2 (38.4 kBaud), COM3 (230.4 kBaud)
IO-Link, Minimum Cycle Time
Device 3,2 ms, Master 5 ms
Insensitivity Test To Shock
according to EN 61131-2
Encoder Inputs, Signal Range
5 V differential (RS422)
Ethernet Supported Protocols
TCP/IP, EasyIP, Modbus TCP
Ethernet, Data Transfer Speed
10/100 Mbit/s
Corrosion Resistance Class KBK
0 - No corrosion stressing
Digital Inputs, Status Display
LED
IO-Link Master, Output Current
3.5 A / port
IO-Link, Connection Technology
Cage Clamp, Plug, Device 3 pin, Master 5-pin
IO-Link, Process Data Width IN
Master parameterisable, 2-32 Byte
Digital Inputs, Switching Logic
Positive logic (PNP)
Digital Outputs, Output Voltage
24 V DC
Digital Outputs, Status Display
LED
IO-Link, Process Data Width OUT
Master parameterisable, 2-32 Byte
Serial Interface, Transfer Rate
300 ... 375000 Bit/s
Digital Outputs, Switching Logic
Positive logic (PNP)
Insensitivity Test To Vibrations
according to EN 61131-2
Nominal Operating Voltage DC (V)
24
Fieldbus Interface, Transfer Rate
125, 250, 500, 800, 1000kbit/s, can be set via software
Digital Inputs, Input Signal Delay
3 ms type
Digital Inputs, Quick Number Inputs
2, However max. 180 kHz
Digital Inputs, Potential Separation
Yes, opto coupler
Digital Outputs, Output Current (mA)
500
Digital Outputs, Short Circuit Proof
yes
Digital Outputs, Switching Frequency
max. 1 kHz
Electrical Connection Technology I/O
Bushing strip, pitch 3.5 mm
IO-Link, Operation-readiness Display
L+ LED green on, L+ LED green off
Digital Outputs, Potential Separation
Yes, opto coupler
Encoder Inputs, Sensor Supply Voltage
5 V DC (100 mA)
Digital Inputs, Nominal Value For TRUE
>= 15 VDC
Digital Inputs, Input Voltage / Current
24 V DC
Digital Inputs, Nominal Value For FALSE
<= 5 VDC
Serial Interface, Connection Technology
Plug
Fieldbus Interface, Connection Technology
Sub-D, 9 pin, Plug
Encoder Inputs, Max. Input Frequency (kHz)
1.000
Fieldbus Interface, Galvanically Separated
yes
CE Certificate (See Declaration Of Conformity)
to EU EMC directive
EAN
4052568223076
Manufacturer
Festo
