Festo - DPDM-Q-6-15-P-PA-4830976 - Compact Cylinder

SKU: festo-dpdm-q-6-15-p-pa-4830976

Browse all parts
Festo - DPDM-Q-6-15-P-PA-4830976 - Compact Cylinder

€88.00€75.21 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€88.00

Brand
Festo
Variants
One-sided piston rod
Dampening
P: Elastic silencer rings / plates double-sided
Stroke (mm)
15
Cover Material
Aluminium wrought alloy
Fastening Type
With throughway bores, With female thread, Selectively:
Seals Material
TPE-U(PU)
Housing Material
Aluminium wrought alloy, anodised
Operating Medium
Compressed air to ISO 8573-1:2010 [7:4:4]
Position Detection
For proximity switch
Construction Set Up
Piston, piston rod, profile tube
Material Information
RoHs compliant
High-alloyed stainless steels
Piston Diameter (mm)
6
Pneumatic Connection
M5
Installation Position
arbitrary
Principle Of Operation
single action, Pulling
Anti-twist Lock / Guide
Guide rod with yoke
Operating Pressure (bar)
2.5 to 8
Corrosion Resistance Class KBK
1 - low corrosion stress
Moving Mass At 0 mm Stroke (g)
7,5
Weight Supplement Per 10 mm Stroke (g)
6,3
Theoretical Force At 6 bar, Return Flow (N)
9
Information About Operating And Control Medium
Oiled operation possible (required in further operations)
EAN
4052568292751
Manufacturer
Festo
