Festo - KP-20-1400-178458 - Locking Cartridge

SKU: festo-kp-20-1400-178458

Browse all parts
Festo - KP-20-1400-178458 - Locking Cartridge

€506.63€433.02 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€506.63

Brand
Festo
Variants
One-sided piston rod
Seals Material
TPE-U(PU)
Piston Material
POM
Spring Material
spring steel
Housing Material
eloxiert
Operating Medium
Compressed air to ISO 8573-1:2010 [7:4:4]
Clamp Jaws Material
Brass
Construction Set Up
Tilting plates
Installation Position
arbitrary
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Release Pressure (MPa)
0,3
Operating Pressure (MPa)
0,3 to 1
Static Holding Force (N)
1.400
Ambient Temperature (°C)
-10 to 80
Corrosion Resistance Class KBK
2 - moderate corrosion stress
Round Stock To Be Clamped (mm)
20
Note On Operating And Control Medium
Oiled operation possible (required in further operations)
Terminal Type With Effective Direction
Klemmung durch Feder, lösen durch Druckluft
EAN
4052568004903
Manufacturer
Festo
