Festo - MHJ9-MF-553115 - Solenoid Valve

SKU: festo-mhj9-mf-553115

Browse all parts
Festo - MHJ9-MF-553115 - Solenoid Valve

€70.15€59.96 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€70.15

Brand
Festo
B-value
0.38
C-value
0,4
Reset Mode
Pneumatic spring
Control Type
Direct
Material Note
RoHs compliant
Power-on Time
100%
Actuation Type
Electrical
Fastening Type
on connection plate
Flow Direction
Not reversible
Seals Material
HNBR
Valve Function
2/2 closed monostable
Screws Material
Steel
Build Width (mm)
9
Housing Material
PA reinforced
Operating Medium
Compressed air to ISO 8573-1:2010 [7:4:4]
Sealing Principle
Hard
Construction Set Up
Poppet valve without reset spring
Protection Category
IP40
Pitch Dimension (mm)
9,5
Coil Resistance (Ohm)
2,5
Electrical Connection
Plug KMH
Hand Assist Actuation
None
Installation Position
arbitrary
LABS (PWIS) Conformity
VDMA24364-B2-L
Pneumatic Connection 1
Connection plate
Pneumatic Connection 2
Connection plate
Medium Temperature (°C)
-5 to 60
Operating Pressure (MPa)
0,05 to 0,6
Ambient Temperature (°C)
-5 to 60
Bearing Temperature (°C)
-20 to 50
Tolerance Shifting Time Off
-0,6
Max. Switching Frequency (Hz)
1.000
Corrosion Resistance Class KBK
2 - moderate corrosion stress
Operating Voltage Range DC (V)
12 to 53
Tolerance Shifting Time On (%)
±15
Limits Ambient And Media Temperature
in Abhängigkeit von der Schaltfrequenz (siehe Diagramm)
Note On Operating And Control Medium
Oiled operation not possible
Max. Tightening Torque Valve Fastening (Nm)
0,28
Permissible Surface Temperature Magnet (°C)
120
Standard Nominal Flow Rate (Standardised To DIN 1343)
100
Switching Time On 0.4 MPa (4 bar, 58 psi) And 12 V In New Condition (ms)
1,1
Switching Time On 0.4 MPa (4 bar, 58 psi) And 24 V In New Condition (ms)
0,8
Switching Time On 0.4 MPa (4 bar, 58 psi) And 48 V In New Condition (ms)
0,6
Switching Time On 0.6 MPa (6 bar, 87 psi) And 24 V In New Condition (ms)
0,90
Switching Time Off 0.4 MPa (4 bar, 58 psi) And 12 V In New Condition (ms)
0,4
Switching Time Off 0.4 MPa (4 bar, 58 psi) And 24 V In New Condition (ms)
0,4
Switching Time Off 0.4 MPa (4 bar, 58 psi) And 48 V In New Condition (ms)
0,4
Switching Time Off 0.6 MPa (6 bar, 87 psi) And 24 V In New Condition (ms)
0,40
Switching Time On 0.05 MPa (0.5 bar, 7.25 psi) And 24 V In New Condition (ms)
0,7
Switching Time Off 0.05 MPa (0.5 bar, 7.25 psi) And 24 V In New Condition (ms)
0,5
EAN
4052568095734
Manufacturer
Festo
