Festo - MS9-FRM-G-VS-564145 - Branch Module

SKU: festo-ms9-frm-g-vs-564145

Browse all parts
Festo - MS9-FRM-G-VS-564145 - Branch Module

€55.82€47.71 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€55.82

Brand
Festo
Size
9
Model Series
MS
Material Note
RoHs compliant
Cover Material
PA reinforced
Fastening Type
With Accessories
Housing Material
Aluminium die casting
Operating Medium
Compressed air to ISO 8573-1:2010 [7:4:4]
Construction Set Up
Branching module
Installation Position
arbitrary
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Pneumatic Connection 3
G1
Pneumatic Connection 4
G1
Medium Temperature (°C)
60
Operating Pressure (bar)
0 to 20
Ambient Temperature (°C)
60
Bearing Temperature (°C)
60
Connection Plate Material
Aluminium die casting
Module Connector Material
Aluminium die casting
Mounting Bracket Material
Aluminium die casting
Corrosion Resistance Class KBK
2 - moderate corrosion stress
Operating Voltage Range AC (V)
0 to 250
Operating Voltage Range DC (V)
0 to 125
Note On Operating And Control Medium
Oiled operation possible
Cleanroom Suitability, Measured According To ISO 14644-14
Klasse 7 nach ISO 14644-1
EAN
4052568099855
Manufacturer
Festo
