Festo - NEBS-L1G4-K-2.5-LE4-572576 - Connection Line

SKU: festo-nebs-l1g4-k-2-5-le4-572576

Browse all parts
Festo - NEBS-L1G4-K-2.5-LE4-572576 - Connection Line

€14.89€12.73 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€14.89

Brand
Festo
Wire Ends
Cut dull
Cable Set Up
4 x 0,17 mm²
Material Note
RoHs compliant
Housing Colour
white
Line Properties
Standard
Cable Length (m)
2,5
Housing Material
PA
Line Designation
With Sign carrier
Cable Diameter (mm)
4,1
Cable Shield Colour
Grey
Protection Category
IP40
Connection Frequency
100
Test Conditions Line
Prüfbedingungen nach Anfrage
Cable Sleeve Material
PVC
LABS (PWIS) Conformity
VDMA24364-Zone III
Plug Contacts Material
Bronze verzinnt
Degree Of Contamination
2
Tolerance Cable Diameter
± 0,15 mm
Ambient Temperature (°C)
-20 to 60
Bearing Temperature (°C)
-20 to 60
Insulation Sleeve Material
PVC
Surge Voltage Strength (kV)
0,8
Corrosion Resistance Class KBK
4 - particularly severe corrosion stress
Operating Voltage Range DC (V)
0 to 30
Electrical Connection 1, Design
Angular
Conductor - Nominal Cross-section
0,17
Electrical Connection 1, Function
Field device screen
Electrical Connection 2, Function
Control screen
Electrical Connection 1, Cable Output
straight
Information About Protection Category
In mounted condition
Current Carrying Capacity At 40 °C (A)
1
Electrical Connection 1, Fastening Type
Ratcheting lock
Electrical Connection 1, Connection Type
socket / container / ….
Electrical Connection 2, Connection Type
cable
Bending Radius, Moving Cable Placement (mm)
42
Electrical Connection 1, Connection Pattern
995720
Electrical Connection 1, Occupied Pin / Wire
4
Electrical Connection 2, Occupied Pin / Wire
4
UKCA Marking (See Declaration Of Conformity)
nach UK RoHS Vorschriften
Bending Radius, Permanent Cable Placement (mm)
13
CE Certificate (See Declaration Of Conformity)
nach EU-RoHS-Richtlinie
Electrical Connection 1, Connection Technology
Wiring diagram L1J
Electrical Connection 2, Connection Technology
Open end
Electrical Connection 1, Number Of Pins / Wires
4
Electrical Connection 2, Number Of Pins / Wires
4
Ambient Temperature For Moving Cable Placements (°C)
-5 to 60
EAN
4052568058890
Manufacturer
Festo
