Permission
c UL us - Listed (OL)
Display Type
Illuminating LCD Multiple
Material Note
RoHs compliant
Control Output
2 x PNP or 2 x NPN switchable
Fastening Type
With Accessories
Flow Direction
bidirektional
Setting Options
Via display and buttons
Switch Function
Auto Differenz Überwachung
Housing Material
PA reinforced
IO-Link, Profile
Smart sensor profile
Tamper-proof Fuse
PIN code
Certification Body
UL E322346
Measured Parameter
Volumenstrom
Overload Resistant
Available
Accuracy Flow Value
± (2% o.m.v. + 1% FS)
Measurement Process
Heat Transfer
Presentable Unit(s)
scft/min
Pneumatic Connection
für Schlauch-Außen-Ø 6 mm
Installation Position
arbitrary
Measurement Principle
Thermic
LABS (PWIS) Conformity
VDMA24364-B2-L
Max. Output Current (mA)
100
Medium Temperature (°C)
0 to 50
Operating Pressure (bar)
-0.9 to 10
Short Circuit Resistance
yes
Ambient Temperature (°C)
0 to 50
IO-Link, Function Classes
Teach channel
IO-Link, Protocol Version
Device V 1.1
IO-Link, SIO Mode Support
yes
Nominal Temperature (°C)
23
Switching Element Function
Opener/closer switchable
IO-Link, Communication Mode
COM2 (38.4 kBaud)
IO-Link, Data Memory Needed
500
Reverse Polarity Protection
for all electrical connections
IO-Link, Service Data Unit IN
32 bit Volumen-/Massemesswert
Repeatability Clamp In ± %FS
0,8
Corrosion Resistance Class KBK
2 - moderate corrosion stress
IO-Link, Process Data Width IN
3 Bytes
Operating Voltage Range DC (V)
22 to 26
Flow Measurement Range End Value
5
From Medium Contacting Materials
High-alloyed stainless steels
IO-Link, Minimum Cycle Time (ms)
4
IO-Link, Process Data Contents IN
2 bit BDC (Durchflussüberwachung)
Pressure Influence Span In ± %FS
1
Repeatability Null Point In ± %FS
0,2
Flow Characteristic Curve End Value
5
Min. Load Resistance Voltage Output
20
Flow Measurement Range Starting Value
0,1
Electrical Connection 1, Fastening Type
nicht drehbar
Pneumatic Connection, Connection Outlet
straight
Electrical Connection 1, Connection Type
Plug
Flow Characteristic Curve Starting Value
-5,0
Temperature Coefficient Clamp (± %FS/K)
type 0,15%FS/K
Max. Load Resistance Current Output (Ohm)
500
Electrical Connection 1, Connection Pattern
991171
UKCA Marking (See Declaration Of Conformity)
nach UK RoHS Vorschriften
CE Certificate (See Declaration Of Conformity)
nach EU-RoHS-Richtlinie
Electrical Connection 1, Connection Technology
M8x1, A coded to EN 61076-2-104
Electrical Connection 1, Number Of Pins / Wires
4
Electrical Connection 1, Compatible Type Of Mounting
Kompatibel mit Schraubverriegelung drehbar
Cleanroom Suitability, Measured According To ISO 14644-14
Klasse 4 nach ISO 14644-1
