Permission
c UL us - Listed (OL)
Material Note
RoHs compliant
Control Output
2 x PNP or 2 x NPN switchable
Switch Function
Freely programmable
Fluid Connection
female thread G3/4
Housing Material
PA reinforced
IO-Link, Profile
Smart sensor profile
Operating Medium
neutrale Flüssigkeiten
Measured Parameter
Temperatur
Overload Resistant
Available
Accuracy Flow Value
±3 % o.m.v. für Durchfluss >= 50 %FS
Measurement Process
Temperatur: PT1000
Installation Position
arbitrary
LABS (PWIS) Conformity
VDMA24364-B2-L
Max. Output Current (mA)
100
Medium Temperature (°C)
0 to 90
Operating Pressure (MPa)
0 to 1,2
Repeatability Flow Value
< ±1 % o.m.v. für Durchfluss >= 50 %FS
Short Circuit Resistance
yes
Ambient Temperature (°C)
0 to 50
IO-Link, Function Classes
Teach channel
IO-Link, Protocol Version
Device V 1.1
IO-Link, SIO Mode Support
yes
Nominal Temperature (°C)
23
Switching Element Function
Opener/closer switchable
IO-Link, Communication Mode
COM2 (38.4 kBaud)
IO-Link, Data Memory Needed
500
Reverse Polarity Protection
for all electrical connections
IO-Link, Service Data Unit IN
32 bit Volumenmesswert
Corrosion Resistance Class KBK
3 - severe corrosion stress
IO-Link, Process Data Width IN
3 Bytes
Operating Voltage Range DC (V)
18 to 30
IO-Link, Process Data Width OUT
0 Bytes
Accuracy Temperature In ± (°C)
2
Flow Measurement Range End Value
100
From Medium Contacting Materials
PA6T/6I verstärkt
IO-Link, Minimum Cycle Time (ms)
5
IO-Link, Process Data Contents IN
2 bit BDC (Durchflussüberwachung)
Flow Characteristic Curve End Value
100
Min. Load Resistance Voltage Output
15
Information About Operating Pressure
max. 0,6 MPa (6 bar / 87 psi) bei 90°C
Note On Operating And Control Medium
Medien mit einer kinematischen Viskosität = 1.8 mm²/sec. [cSt]. Die Medienverträglichkeit zu den medienberührenden Stoffen muss gewährleistet sein.
Flow Measurement Range Starting Value
5
Electrical Connection 1, Fastening Type
nicht drehbar
Electrical Connection 1, Connection Type
Plug
Flow Characteristic Curve Starting Value
0
Temperature Coefficient Clamp (± %FS/K)
type ±0,05%FS/K
Max. Load Resistance Current Output (Ohm)
500
Electrical Connection 1, Connection Pattern
995383
UKCA Marking (See Declaration Of Conformity)
nach UK RoHS Vorschriften
CE Certificate (See Declaration Of Conformity)
nach EU-RoHS-Richtlinie
Electrical Connection 1, Connection Technology
M12x1 A-codiert nach EN 61076-2-101
Electrical Connection 1, Number Of Pins / Wires
5
Electrical Connection 1, Compatible Type Of Mounting
Kompatibel mit Schraubverriegelung drehbar
