Festo - SOEC-RT-Q50-PS-S-7L-538236 - Color Sensor

SKU: festo-soec-rt-q50-ps-s-7l-538236

Browse all parts
Festo - SOEC-RT-Q50-PS-S-7L-538236 - Color Sensor

€1,432.48€1,224.34 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€1,432.48

Brand
Festo
Size
50x50x17 mm
Design
Block structure
Light Type
white
Permission
c UL us - Listed (OL)
Range (mm)
12 to 32
Material Note
RoHs compliant
Control Output
PNP
Fastening Type
With throughway bores
Max. Light Spot
Ø 4 mm at sampling width 22 mm
Residual Ripple
10%
Setting Options
Teach-In über elektrischen Anschluss
Housing Material
ABS
Voltage Drop (V)
2,4
Measured Parameter
Position
Measurement Process
Colour sensor
Protection Category
IP67
Complies To Standard
EN 60947-5-2
Electrical Connection
Plug
Measurement Principle
Optoelectronic
Empty Run Current (mA)
40
LABS (PWIS) Conformity
VDMA24364-B2-L
Max. Output Current (mA)
100
Short Circuit Resistance
Cycling
Ambient Temperature (°C)
-10 to 55
Switching Element Function
Bright switching
Switching Status Indicator
LED
Operation-readiness Display
LED green
Reverse Polarity Protection
for all electrical connections
Max. Switching Frequency (Hz)
500
Corrosion Resistance Class KBK
4 - particularly severe corrosion stress
Operating Voltage Range DC (V)
10 to 30
Settings Range Lower Limit (mm)
12
Settings Range Upper Limit (mm)
32
UKCA Marking (See Declaration Of Conformity)
nach UK RoHS Vorschriften
CE Certificate (See Declaration Of Conformity)
nach EU-RoHS-Richtlinie
Ambient Temperature For Moving Cable Placements (°C)
-5 to 55
EAN
4052568175399
Manufacturer
Festo
