Festo - SPTE-V1R-Q4-V-2.5K-571477 - Pressure Transmitter

SKU: festo-spte-v1r-q4-v-2-5k-571477

Browse all parts
Festo - SPTE-V1R-Q4-V-2.5K-571477 - Pressure Transmitter

€75.66€64.67 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€75.66

Brand
Festo
Permission
c UL us - Recognized (OL)
Material Note
RoHs compliant
Fastening Type
With Accessories
Rise Time (ms)
1
Analogue Output
0 - 10 V
Gasket Material
NBR
Cable Length (m)
2,5
Housing Material
PA reinforced
Operating Medium
Compressed air to ISO 8573-1:2010 [7:4:4]
Certification Body
UL E322346
Measured Parameter
Relative pressure
Accuracy In ± % FS
3
Measurement Process
Piezoresistive pressure sensor
Protection Category
IP40
Pneumatic Connection
QS-4
Electrical Connection
Open end
Installation Position
arbitrary
LABS (PWIS) Conformity
VDMA24364-B2-L
Overload Pressure (MPa)
0,5
Repeatability In ± %FS
0,3
Medium Temperature (°C)
0 to 50
Short Circuit Resistance
for all electrical connections
Ambient Temperature (°C)
0 to 50
Reverse Polarity Protection
for all electrical connections
Corrosion Resistance Class KBK
2 - moderate corrosion stress
Operating Voltage Range DC (V)
18 to 30
Min. Load Resistance Voltage Output
15
Temperature Coefficient In ± %FS/K
0,05
Note On Operating And Control Medium
Oiled operation possible
Pressure Measurement Range End Value (MPa)
-0,1
UKCA Marking (See Declaration Of Conformity)
nach UK RoHS Vorschriften
CE Certificate (See Declaration Of Conformity)
nach EU-RoHS-Richtlinie
Pressure Measurement Range Starting Value (MPa)
0
Cleanroom Suitability, Measured According To ISO 14644-14
Klasse 4 nach ISO 14644-1
EAN
4052568101312
Manufacturer
Festo
