Festo - VABA-S6-1-X5-8154036 - Pneumatic Connection

SKU: festo-vaba-s6-1-x5-8154036

Browse all parts
Festo - VABA-S6-1-X5-8154036 - Pneumatic Connection

€441.66€377.49 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€441.66

Brand
Festo
Material Note
phosphorsäureesterfrei
Cover Material
Zink-Druckguss, pulverbeschichtet
Fastening Type
mit Durchgangsbohrung für Schraube M6
Seals Material
PUR
Screws Material
Nickel-plated steel
Housing Material
Aluminium
Module Parameter
Verhalten im Fehlerzustand
Protection Class
III
Shock Resistance
Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27
Diagnosis Via LED
Spannungsversorgung Last
Relative Humidity
Not condensing
Electrical Controls
Fieldbus
Internal Cycle Time
< 1 ms
Dimensions W x L x H
70,5 mm x 142 mm x 102,6 mm
Fuse (Short Circuit)
Internal electronic fuse Per valve outlet
Oscillation Strength
Transport use test with severity level 2 to FN 942017-4 and EN 60068-2-6
Max. Setup Height (m)
3.500
Module Code (Hex/dec)
0x3044/12356d
Over-voltage Category
II
LABS (PWIS) Conformity
VDMA24364-B2-L
Degree Of Contamination
2
Nominal Altitude Of Use
<= 2000 m ASL (> 79,5 kPa)
Ambient Temperature (°C)
-20 to 50
Bearing Temperature (°C)
-20 to 70
Switch On Valve Terminals
Typ 45, VTSA-F
Max. Number Of Valve Coils
32
Reverse Polarity Protection
yes
Power Blackout Bridging (ms)
10
Corrosion Resistance Class KBK
0 - No corrosion stressing
Max. Number Of Valve Positions
32 bei monostabilen Ventilen
Communication Interface, Protocol
AP
Diagnostics Per Internal Communication
Unterspannung Last
Permissible Voltage Fluctuation Of Load
± 10 %
Nominal Operating Voltage DC Of Load (V)
24
Intrinsic Power Input Operating Voltage Load
typisch 17 mA
Undervoltage Load/valves (Diagnostic Message) (V)
21,6
Permitted Voltage Oscillations Electronics/sensors
± 25 %
Nominal Operating Voltage DC Electronics / Sensor (V)
24
Intrinsic Power Input Operating Voltage Electronics/sensors
typisch 27 mA
Potential Separation Between The Supply Voltages Electronics/sensor Technology And Load/valves
yes
EAN
4052568614560
Manufacturer
Festo
