Festo - VASB-100-1/4-NBR-35416 - Vacuum Sucker

SKU: festo-vasb-100-1-4-nbr-35416

Browse all parts
Festo - VASB-100-1/4-NBR-35416 - Vacuum Sucker

€64.58€55.20 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€64.58

Brand
Festo
Colour
black
Material Note
RoHs compliant
Stud Material
Zinc pressure cast
Shore Hardness
60 ± 5
Mounting Thread
G1/4
Operating Medium
Atmospheric air based on ISO 8573-1:2010 [7:-:-]
Suction Cup Shape
Round folding bellows1.5 times
Suction Fastening
G 1/4
Vacuum Connection
G1/4
Nominal Width (mm)
4
Connection Position
top
Suction Cups Material
NBR
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Ambient Temperature (°C)
-20 to 80
Suction Cup Diameter (mm)
100
Effective Suction Diameter (mm)
85
Pull-off Force At 70% Vacuum (N)
397
Holding Force For Nominal Operating Pressure (N)
397,00
EAN
4052568068127
Manufacturer
Festo
