Festo - VLX-2-3/4-MS-NPT-34925 - Pneumatic Valve

SKU: festo-vlx-2-3-4-ms-npt-34925

Browse all parts
Festo - VLX-2-3/4-MS-NPT-34925 - Pneumatic Valve

€456.09€389.82 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€456.09

Brand
Festo
Medium
Filtered compressed air, filter porosity 200 µm
Reset Mode
Pneumatic spring
Control Type
pilot operated
Actuation Type
pneumatic
Control Medium
Compressed air to ISO 8573-1:2010 [7:-:-]
Fastening Type
pipe installation
Flow Direction
Not reversible
Valve Function
2/2 closed monostable
Screws Material
High-alloyed stainless steels
Exhaust Function
Cannot be throttled
Housing Material
Brass
Sealing Principle
Soft
Fitting Connection
NPT3/4
Nominal Width (mm)
20
Construction Set Up
diaphragm valve
Installation Position
arbitrary
Material Number Screw
14.301
Medium Pressure (bar)
1 to 10
LABS (PWIS) Conformity
VDMA24364-B1/B2-L
Medium Temperature (°C)
-10 to 80
Ambient Temperature (°C)
-10 to 60
Support Air Control Connection 12
M5
Standard Nominal Flow Rate (Standardised To DIN 1343)
10500
EAN
4052568305918
Manufacturer
Festo
