Festo - VZBE-3-T-63-D-2-M-V15V16-4745225 - Ball Valve

SKU: festo-vzbe-3-t-63-d-2-m-v15v16-4745225

Browse all parts
Festo - VZBE-3-T-63-D-2-M-V15V16-4745225 - Ball Valve

€572.34€489.18 (Excl. VAT)

Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€572.34

Brand
Festo
Medium
neutrale Flüssigkeiten
Flow Kv
995
Permission
CRN
Ball Material
High-alloyed stainless steels
Material Note
RoHs compliant
Actuation Type
Mechanical
Fastening Type
pipe installation
Flow Direction
Reversible
Seals Material
PTFE
Shaft Material
High-alloyed stainless steels
Housing Material
Cast stainless steel
Nominal Width DN
80
Based On Standard
ASME B1.20.1
Sealing Principle
Soft
Fitting Connection
3 NPT
Construction Set Up
2-Wege-Kugelhahn mit Handhebel
Inner Diameter (mm)
76,0
Nominal Pressure PN
63
Material - Seal Seat
PTFE
Material Number Ball
14.401
Installation Position
arbitrary
Material Number Shaft
14.401
LABS (PWIS) Conformity
VDMA24364-Zone III
Material Number Housing
14.408
Medium Temperature (°C)
-20 to 200
Switching Position Display
Carriage direction = flow direction
Corrosion Resistance Class KBK
3 - severe corrosion stress
CE Certificate (See Declaration Of Conformity)
to EU pressure vessel directive
Break-out Torque At A Pressure Difference Nominal Fitting Pressure PN (Nm)
85,0
EAN
4052568275167
Manufacturer
Festo
