HELLA - 2XD 011 557-701 - LED-Strobe-type Beacon, K-LED 2.0 F, 12/24V, yellow (amber)
HELLA - 2XD 011 557-701 - LED-Strobe-type Beacon, K-LED 2.0 F, 12/24V, yellow (amber)
HELLA - 2XD 011 557-701 - LED-Strobe-type Beacon, K-LED 2.0 F, 12/24V, yellow (amber)
HELLA - 2XD 011 557-701 - LED-Strobe-type Beacon, K-LED 2.0 F, 12/24V, yellow (amber)
HELLA - 2XD 011 557-701 - LED-Strobe-type Beacon, K-LED 2.0 F, 12/24V, yellow (amber)
HELLA - 2XD 011 557-701 - LED-Strobe-type Beacon, K-LED 2.0 F, 12/24V, yellow (amber)

In stock - ready to ship

Order now for delivery between 27 May and 30 May
Free shipping

Pay Securely with

HELLA - 2XD 011 557-701 - LED-Strobe-type Beacon, K-LED 2.0 F, 12/24V, yellow (amber)

HELLA - 2XD 011 557-701 - LED-Strobe-type Beacon, K-LED 2.0 F, 12/24V, yellow (amber)

€188.59

(Excl. VAT)

Price

(Excl. VAT)

€188.59

Product Description

The K-LED 2.0 beacon provides both a rotating and a flashing warning signal in one product. The signal is generated by means of an electronic concept and thus without moving parts and offers 16 different flash sequences. Thanks to the integrated "day/night mode", the brightness is adjusted to the ambient light by means of a sensor. This ensures increased visibility during the day and the avoidance of glare at night. The beacon can be connected to an operating voltage of 10 - 32 V. It is also very flat and has an impact-resistant polycarbonate light bonnet that protects against shocks. The height of the K-LED 2.0 is approx. 87.6 mm (F) to 160.6 mm (R), depending on the design. It meets the requirements of IP67 and is therefore dustproof and can be immersed in water for short periods. The product is attached to the vehicle by means of screws in the case of fixed mounting or by means of a pipe socket or magnetic adapter in the case of the other variants. The beacon is particularly suitable as an attention-grabbing warning signal and for safeguarding danger spots.
Hella
Hella is a supplier of lighting and electronic systems for agricultural and off-road vehicles. The brand provides LED work lights, signal lamps, and electrical components for tractors and machinery. Its products are designed for durability and visibility in harsh farming environments. Shop more than 6,960 genuine Hella spare parts.

Product Details

Brand
HELLA
Equivalent OEM Part Numbers

Aebi

1218718-0

Bucher

1076553

Faun

5184377

Goldhofer

126382

Mafi

0005800741

Rosenbauer

56683A
Plug
Blade Terminal
Cable
200 mm
Height
88 mm
Weight
885 g
Version
Airport Beacon
Voltage
24 V / 12 V
Quantity
1
Lamp Type
LED
LED colour
White
Lens Colour
Yellow (amber)
Light Design
LED
Light colour
Yellow (amber)
Assembly Note
Assembly by qualified personnel required
Mounting Type
Bolted
Housing Colour
Silver
Light Function
With flashing warning signal / With rotating warning signal
Number of LEDs
20
Housing material
Aluminium
Outer Diameter 1
169 mm
Power consumption
30 W
Registration Type
ECE / SAE / ICAO-tested
Prot.type (IP Code)
IP6K7 / IP6K9K
Rotating beacon RPM
75 1/min
Fulfils ECE standard
R10
Fulfils SAE standard
J845 Class 1
Temperature range to
+60 °C
Flash rate per minute
75
Temperature range from
-40 °C
Diffusing Lens Material
PC (Polycarbonate)
Fulfils EMC/CISPR standard
Class 5
Supplementary Article/Supplementary Info 2
Electromagnetic Compatibility (EMC)
Manufacturer
HELLA
