HELLA - 2XD 014 561-601 - LED-Strobe-type Beacon, BST, 12/24V, Red
HELLA - 2XD 014 561-601 - LED-Strobe-type Beacon, BST, 12/24V, Red
Available for backorder – we will confirm the soonest available delivery date within 1 business day after ordering
Free shipping

Pay Securely with

HELLA - 2XD 014 561-601 - LED-Strobe-type Beacon, BST, 12/24V, Red

HELLA - 2XD 014 561-601 - LED-Strobe-type Beacon, BST, 12/24V, Red

€142.13

(Excl. VAT)

Price

(Excl. VAT)

€142.13

Product Description

The BST warning light is available in different signal colours, dimensions and mounting variants. 3 or 6 power LEDs in the colours yellow, blue, red or white ensure an optimal signalling effect. The light can be synchronised with two or more units and has different flash sequences. In addition to the continuous light function, four different flash patterns can be set and are approved according to the European directive for beacons ECE-R65. The warning signal (single to quadruple flash) is either synchronous or alternating. Variants with "1 level" produce a constant level of brightness independent of the ambient light. Variants with "day/night mode", adjust the brightness to the ambient light. This ensures increased visibility during the day and the avoidance of glare at night. The housing is attached to the vehicle by means of screws for fixed mounting and by means of a bracket for bracket mounting. The warning system is also available as a slim version with a mounting height of only 12.8 mm. It is particularly suitable as an attention-grabbing warning signal and for safeguarding danger spots. The product can be mounted horizontally or vertically in various positions around the vehicle, depending on the variant.
Hella
Hella is a supplier of lighting and electronic systems for agricultural and off-road vehicles. The brand provides LED work lights, signal lamps, and electrical components for tractors and machinery. Its products are designed for durability and visibility in harsh farming environments. Shop more than 6,960 genuine Hella spare parts.

Product Details

Brand
HELLA
Equivalent OEM Part Numbers

Manitou

52715532
Plug
Open cable ends
Cable
200 mm
Height
28 mm
Weight
116 g
Voltage
12 V / 24 V
Quantity
2
Lamp Type
LED
LED Colour
Red
Lens Colour
Crystal clear
Light Colour
Red
Light Design
LED
Mounting Type
Screw Connection / mounting
Quantity Unit
Kit
Fastening Type
For horizontal fastening
Housing Colour
Black
Light Function
With flashing warning signal
Number of LEDs
3
Housing Material
Aluminium
Power Consumption
14 W
Fulfils ECE Standard
R10 / R65
Temperature Range To
+60 °C
Temperature Range From
-40 °C
Diffusing Lens Material
PC (Polycarbonate)
Protection Type (IP Code)
IP5K4K / IP6K9K / IPX9K
Supplementary Article/Supplementary Info
Follow nat. rules for attachment, install. and operation. Assembly by qualified personnel required!
Manufacturer
