INA FAG - 209NPPB - Y-Bearing with Convex Outer Ring
INA FAG - 209NPPB - Y-Bearing with Convex Outer Ring
INA FAG - 209NPPB - Y-Bearing with Convex Outer Ring
INA FAG - 209NPPB - Y-Bearing with Convex Outer Ring
INA FAG - 209NPPB - Y-Bearing with Convex Outer Ring

In stock - ready to ship

Ships within 112 hours
Free shipping on orders over €60

Pay Securely with

INA FAG - 209NPPB - Y-Bearing with Convex Outer Ring

INA FAG - 209NPPB - Y-Bearing with Convex Outer Ring

€39.07

(Excl. VAT)

Price

(Excl. VAT)

€39.07

Product Description

The INA-FAG 209NPPB is a high-quality Y-bearing (insert bearing) designed for demanding agricultural and industrial applications. Featuring a 45 mm bore diameter and an 85 mm outer diameter, this bearing includes a spherical outer ring to compensate for initial misalignment. It is equipped with an eccentric locking collar for secure shaft attachment and robust lip seals on both sides for protection against contaminants. The bearing also includes relubrication grooves and holes, ensuring extended service life and reliable performance in harsh environments.
INA FAG
Ina-fag is a supplier of precision bearings and components for agricultural machinery. The brand offers high-quality bearings for tractors, harvesters, and other heavy-duty equipment. Ina-fag products are engineered to withstand harsh farming conditions and reduce maintenance needs. Shop more than 15,678 genuine Ina-fag spare parts.

Product Details

Brand
INA/FAG
Part Numbers
209nppb
Equivalent OEM Part Numbers

Fag

GRAE45NPPB209

Skf

YAR209-2F

Koyo

GE45KPPB2

Ntn

AEL209-2F
Unit
Each
BWidth
19 mm
Weight
0,037 kg
Sealing
2RS
Properties
Single-row roller bearing Lip seal on both sides Convex outer ring No subsequent lubrication possible
Regreasable
No
dInside diameter
45 mm
BOuter ring width
19 mm
DOutside diameter
85 mm
Bearing model type
Deep groove ball bearings
Max rotation speed
9600 r/min
Basic radial load static
20400 N
Basic radial load dynamic
32500 N
FOutside diameter of inner ring
53,2 mm
EAN
4012802782417
Manufacturer
INA/FAG
