INA FAG - 22122RSTVHC3 - FAG Self-Aligning Ball Bearing

OEM Supplier

SKU: ina-fag-22122rstvhc3

INA FAG - 22122RSTVHC3 - FAG Self-Aligning Ball Bearing

€74.49

(excl. VAT)

In stock - ready to ship

Ships within 96 hours
Free shipping

Pay Securely with

Price

(Excl. VAT)

€74.49

The INA-FAG 2212-2RS-TVH-C3 is a high-quality self-aligning ball bearing designed for applications where angular misalignment may occur. Featuring a 60mm bore diameter, 110mm outer diameter, and 28mm width, this bearing ensures reliable performance. It is equipped with 2RS contact seals on both sides to protect against contaminants and retain lubricant, extending service life. The TVH glass fibre reinforced polyamide cage provides excellent strength and temperature resistance. With C3 internal clearance, it is suitable for applications requiring greater than normal operating clearance, accommodating thermal expansion and misalignment effectively. Manufactured by FAG, a Schaeffler brand, it guarantees OEM quality and precision.
INA FAG
INA and FAG are two prominent brands under the Schaeffler Group, a global automotive and industrial supplier based in Herzogenaurach, Germany. FAG was founded in 1883 by Friedrich Fischer in Schweinfurt, Germany, and is recognized as a pioneer in the rolling bearing industry. INA was established in 1946 by Dr. Georg Schaeffler and Dr. Wilhelm Schaeffler in Herzogenaurach. Both brands were acquired by Schaeffler, forming a powerful combination in bearing technology and precision components. The Schaeffler Group, through its INA and FAG brands, offers an extensive portfolio of high-precision components and systems for various industrial applications, including agricultural machinery. FAG is particularly known for its rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, suchers as rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, such as cam followers, tensioner pulleys, and clutch release bearings, as well as specific bearing solutions. Their products are engineered for durability, efficiency, and performance in demanding environments. At Partao, you can find a wide range of genuine INA FAG spare parts across top categories such as Ball Bearings, Air Filters, Axle Seals, Battery Chargers, and Bearing Housings. These components are critical for the smooth operation and longevity of various agricultural machines, from tractors to harvesters, ensuring reliable power transmission and reduced friction. Over 1717,174 genuine INA FAG spare parts are available at Partao. INA FAG components are trusted by agricultural machinery manufacturers and operators worldwide due to their reputation for precision engineering and robust construction. The brands' products are designed to withstand the harsh conditions and heavy loads typical in farming operations, contributing to the overall reliability and efficiency of the equipment. Their global presence and commitment to innovation ensure widespread availability and continuous technological advancement.

Brand
Part Numbers
22122rstvhc3
Unit
Each
BWidth
28 mm
Weight
0,114 kg
Sealing
2RS
Material
Steel
Properties
Self-adjusting roller bearing Double row Lip seal on both sides
Rows number
2
Inner ring shape
Cylindrical
dInside diameter
60 mm
Application range
Bearing design with considerable shaft deflection or alignment errors Polluted environments Conveyor belts Plants for steel production
DOutside diameter
110 mm
Bearing model type
Self-aligning ball bearings
Max rotation speed
3450 r/min
Basic radial load static
11500 N
Basic radial load dynamic
30500 N
Radial internal clearance code
C3
EAN
4012801478144
Manufacturer
INA/FAG
