INA FAG - 81106TV - INA Axial Cylindrical Roller Bearing
INA FAG - 81106TV - INA Axial Cylindrical Roller Bearing
INA FAG - 81106TV - INA Axial Cylindrical Roller Bearing
INA FAG - 81106TV - INA Axial Cylindrical Roller Bearing

In stock - ready to ship

Order now for delivery between 12 May and 15 May
Free shipping on orders over €60

Pay Securely with

INA FAG - 81106TV - INA Axial Cylindrical Roller Bearing

INA FAG - 81106TV - INA Axial Cylindrical Roller Bearing

€37.70

(Excl. VAT)

Price

(Excl. VAT)

€37.70

Product Description

The INA 81106TV is a genuine INA axial cylindrical roller bearing, manufactured by Schaeffler. This single direction bearing features a 30 mm bore diameter, a 47 mm outer diameter, and an 11 mm height. It is specifically designed to accommodate high axial loads and provide excellent rigidity in various industrial applications. The 'TV' suffix indicates that the bearing is equipped with a cage made from glass fibre reinforced polyamide, which contributes to its performance characteristics and reduced weight. This robust bearing ensures reliable operation where precise axial guidance and high load capacity are critical.
INA FAG
Ina-fag is a supplier of precision bearings and components for agricultural machinery. The brand offers high-quality bearings for tractors, harvesters, and other heavy-duty equipment. Ina-fag products are engineered to withstand harsh farming conditions and reduce maintenance needs. Shop more than 17,176 genuine Ina-fag spare parts.

Product Details

Brand
INA/FAG
Unit
Each
Speed
3050 r/min
Height
11 mm
TWidth
11 mm
Sealing
Open
Properties
Absorbs axial forces in 1 direction Low axial installation height High load-bearing capacity
Consists of
Cylindrical roller and cage assembly Housing disc Shaft disc
Bore diameter
30 mm
dInside diameter
30 mm
Application range
Reductors Gearbox
DOutside diameter
47 mm
Basic axial load static
86000 N
Basic axial load dynamic
35500 N
D1Inside diameter of outer ring
32 mm
d1Outside diameter of inner ring
47 mm
Limiting speeds (rpm) Grease lub.
7500 r/min
Manufacturer
