INA FAG - KSR16L006102008 - Idler Sprocket

OEM Supplier

SKU: ina-fag-ksr16l006102008

INA FAG - KSR16L006102008 - Idler Sprocket

€26.82

(excl. VAT)

In stock - ready to ship

Ships within 96 hours

Shipping fee: €6.00 excl. VAT

Pay Securely with

Price

(Excl. VAT)

€26.82

The INA KSR16-L0-06-10-20-08 is a high-quality idler sprocket designed for use with roller chains conforming to ISO 606 (DIN 8187), specifically for chain size 06B-1 (3/8 x 7/16 inch). This genuine INA component features a durable polyamide construction with an integrated deep groove ball bearing, ensuring smooth and reliable operation. It has an outside diameter of 20 mm, a width of 8 mm, and a bore diameter of 6 mm, with 10 teeth for efficient chain guidance.
INA FAG
INA and FAG are two prominent brands under the Schaeffler Group, a global automotive and industrial supplier based in Herzogenaurach, Germany. FAG was founded in 1883 by Friedrich Fischer in Schweinfurt, Germany, and is recognized as a pioneer in the rolling bearing industry. INA was established in 1946 by Dr. Georg Schaeffler and Dr. Wilhelm Schaeffler in Herzogenaurach. Both brands were acquired by Schaeffler, forming a powerful combination in bearing technology and precision components. The Schaeffler Group, through its INA and FAG brands, offers an extensive portfolio of high-precision components and systems for various industrial applications, including agricultural machinery. FAG is particularly known for its rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, suchers as rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, such as cam followers, tensioner pulleys, and clutch release bearings, as well as specific bearing solutions. Their products are engineered for durability, efficiency, and performance in demanding environments. At Partao, you can find a wide range of genuine INA FAG spare parts across top categories such as Ball Bearings, Air Filters, Axle Seals, Battery Chargers, and Bearing Housings. These components are critical for the smooth operation and longevity of various agricultural machines, from tractors to harvesters, ensuring reliable power transmission and reduced friction. Over 1717,174 genuine INA FAG spare parts are available at Partao. INA FAG components are trusted by agricultural machinery manufacturers and operators worldwide due to their reputation for precision engineering and robust construction. The brands' products are designed to withstand the harsh conditions and heavy loads typical in farming operations, contributing to the overall reliability and efficiency of the equipment. Their global presence and commitment to innovation ensure widespread availability and continuous technological advancement.

Brand
Part Numbers
ksr16l006102008
Bore
Yes
Type
Simplex
Unit
Each
Width
18,3 mm
Hub type
Plate only
Material
Sintered iron C10
Properties
Bearing has an inner ring extended on both sides
Teeth width
5,2 mm
Bore diameter
16,2 mm
Pitch diameter
60,9 mm
Chain size code
06 B-1
Number of teeth
20
Outside diameter
65 mm
Application range
Clamp ring in chain drive
Teeth hardness range
HB 40-60
Bearing outside diameter
40 mm
EAN
4012802790054
Manufacturer
INA/FAG
