INA FAG - PCJY35 - Square Flange Bearing Set

OEM Supplier

SKU: ina-fag-pcjy35

INA FAG - PCJY35 - Square Flange Bearing Set

€43.28

(excl. VAT)

In stock - ready to ship

Ships within 96 hours

Shipping fee: €6.00 excl. VAT

Pay Securely with

Price

(Excl. VAT)

€43.28

The INA-FAG PCJY35 is a high-quality square flange bearing unit designed for robust performance in various agricultural and industrial machinery. This genuine FAG unit features a 35mm bore diameter, making it suitable for shafts requiring reliable support and smooth rotation. It is a complete bearing unit, pre-assembled and ready for easy mounting, ensuring efficient operation and extended service life. Ideal for applications demanding durability and precision.
INA FAG
INA and FAG are two prominent brands under the Schaeffler Group, a global automotive and industrial supplier based in Herzogenaurach, Germany. FAG was founded in 1883 by Friedrich Fischer in Schweinfurt, Germany, and is recognized as a pioneer in the rolling bearing industry. INA was established in 1946 by Dr. Georg Schaeffler and Dr. Wilhelm Schaeffler in Herzogenaurach. Both brands were acquired by Schaeffler, forming a powerful combination in bearing technology and precision components. The Schaeffler Group, through its INA and FAG brands, offers an extensive portfolio of high-precision components and systems for various industrial applications, including agricultural machinery. FAG is particularly known for its rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, suchers as rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, such as cam followers, tensioner pulleys, and clutch release bearings, as well as specific bearing solutions. Their products are engineered for durability, efficiency, and performance in demanding environments. At Partao, you can find a wide range of genuine INA FAG spare parts across top categories such as Ball Bearings, Air Filters, Axle Seals, Battery Chargers, and Bearing Housings. These components are critical for the smooth operation and longevity of various agricultural machines, from tractors to harvesters, ensuring reliable power transmission and reduced friction. Over 1717,174 genuine INA FAG spare parts are available at Partao. INA FAG components are trusted by agricultural machinery manufacturers and operators worldwide due to their reputation for precision engineering and robust construction. The brands' products are designed to withstand the harsh conditions and heavy loads typical in farming operations, contributing to the overall reliability and efficiency of the equipment. Their global presence and commitment to innovation ensure widespread availability and continuous technological advancement.

Brand
Part Numbers
pcjy35
Aftermarket Part Numbers
Unit
Each
Properties
• Inner bearing has one-sided extended inner ring with 2 adjusting screws Can be subsequently lubricated
Total width
46,45 mm
Housing type
Square flange
ATotal length
118 mm
Housing width
118 mm
UTotal height
46,5 mm
THousing height
30,5 mm
CFlange thickness
10 mm
Mounting holes distance
92 mm
Basic radial load static
15300 N
dBearing inside diameter
35 mm
Basic radial load dynamic
27500 N
LBearing inner ring width
35 mm
Grease nipple thread diameter
M6
Bearing balls distance to locking side end
21 mm
EAN
4012802823882
Manufacturer
INA/FAG
