INA FAG - PHEY20 - Take-up Bearing Unit

INA FAG - PHEY20 - Take-up Bearing Unit

€20.24

(Excl. VAT)

Price

(Excl. VAT)

€20.24

Number of products

Product Description

The INA PHEY20 is a high-quality take-up bearing unit, part of the Schaeffler Group, featuring a robust cast iron housing and an INA GRAE20-NPP-B bearing insert. Designed for applications requiring shaft adjustment, this unit has a 20mm bore and is equipped with RSR seals on both sides for effective protection against contaminants. Pre-lubricated for immediate use, it offers reliable and durable performance in various industrial and agricultural machinery.

INA FAG

Ina-fag is a supplier of precision bearings and components for agricultural machinery. The brand offers high-quality bearings for tractors, harvesters, and other heavy-duty equipment. Ina-fag products are engineered to withstand harsh farming conditions and reduce maintenance needs. Shop more than 17,176 genuine Ina-fag spare parts.

Product Details

Brand

Equivalent AM Part Numbers

Skf

Nsk

Snr

Ntn

Fag

Unit

Each

Weight

0,54 kg

Properties

Inner bearing has one-sided extended inner ring with 2 adjusting screws Subsequent lubrication possible

Total height

65 mm

Total length

91 mm

MHousing width

65 mm

A2Housing height

25 mm

Application range

Mobile mechanical engineering Stationary mechanical engineering

WGuide groove length

38 mm

K1Mounting thread length

21 mm

Mounting thread diameter

M16

dBearing inside diameter

20 mm

BBearing inner ring width

25 mm

L1Shaft vertical distance

58 mm

Grease nipple thread diameter

M6

Manufacturer

INA/FAG
