INA FAG - PME50 - Bearing Block PME 50

OEM Supplier

SKU: ina-fag-pme50

INA FAG - PME50 - Bearing Block PME 50

€78.58

(excl. VAT)

In stock - ready to ship

Ships within 48 hours

Shipping fee: €6.00 excl. VAT

Pay Securely with

Price

(Excl. VAT)

€78.58

The INA-FAG PME50 bearing block is a high-quality plummer block housing designed for spherical roller bearings. This robust unit provides excellent support and protection for bearings in various industrial machinery. Engineered for durability and reliable operation, the PME50 ensures optimal performance and extended service life in demanding environments. It is a genuine INA-FAG component, known for precision and quality.
INA FAG
INA and FAG are two prominent brands under the Schaeffler Group, a global automotive and industrial supplier based in Herzogenaurach, Germany. FAG was founded in 1883 by Friedrich Fischer in Schweinfurt, Germany, and is recognized as a pioneer in the rolling bearing industry. INA was established in 1946 by Dr. Georg Schaeffler and Dr. Wilhelm Schaeffler in Herzogenaurach. Both brands were acquired by Schaeffler, forming a powerful combination in bearing technology and precision components. The Schaeffler Group, through its INA and FAG brands, offers an extensive portfolio of high-precision components and systems for various industrial applications, including agricultural machinery. FAG is particularly known for its rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, suchers as rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, such as cam followers, tensioner pulleys, and clutch release bearings, as well as specific bearing solutions. Their products are engineered for durability, efficiency, and performance in demanding environments. At Partao, you can find a wide range of genuine INA FAG spare parts across top categories such as Ball Bearings, Air Filters, Axle Seals, Battery Chargers, and Bearing Housings. These components are critical for the smooth operation and longevity of various agricultural machines, from tractors to harvesters, ensuring reliable power transmission and reduced friction. Over 1717,174 genuine INA FAG spare parts are available at Partao. INA FAG components are trusted by agricultural machinery manufacturers and operators worldwide due to their reputation for precision engineering and robust construction. The brands' products are designed to withstand the harsh conditions and heavy loads typical in farming operations, contributing to the overall reliability and efficiency of the equipment. Their global presence and commitment to innovation ensure widespread availability and continuous technological advancement.

Brand
Part Numbers
pme50
Unit
Each
Weight
2,13 kg
Benefits
Precise axis alignment possible Fixing points are relieved
Properties
Inner bearing has one-sided extended inner ring with clamp ring Can be subsequently lubricated
Consists of
Bearing block Clamp ring
Total width
43,8 mm
Housing type
Round flange
Total height
31,8 mm
Housing width
165 mm
Housing height
25 mm
Bearing material
Steel
CFlange thickness
17 mm
Fitting edge diameter
110 mm
Basic radial load static
23200 N
KMounting holes diameter
14 mm
dBearing inside diameter
50 mm
Basic radial load dynamic
35000 N
L*Bearing inner ring width
43,8 mm
Grease nipple thread diameter
M6
Locking ring outside diameter
69 mm
EAN
4012802837056
Manufacturer
INA/FAG
