INA FAG - RAE40NPPFA106 - Bearing Insert

OEM Supplier

SKU: ina-fag-rae40nppfa106

INA FAG - RAE40NPPFA106 - Bearing Insert

€77.11€65.91 (Excl. VAT)

In stock - ready to ship

Order now for shipping within 4 to 6 business days

Shipping fee: €9.99 incl. VAT

Pay Securely with

Price

€77.11

Brand
Part Numbers
rae40nppfa106
Aftermarket Part Numbers

Skf

Ntn

Snr

Bore Diameter (mm)
40
Outer Diameter (mm)
80
Width (mm)
49.2
Inner Ring Width (mm)
30.2
Weight (kg)
0.65
Dynamic Load Rating (kN)
25.5
Static Load Rating (kN)
15.3
Limiting Speed (rpm)
4300
Quality
OEM Supplier
Manufacturer
INA FAG

The INA-FAG RAE40NPPFA106 is a high-quality radial insert ball bearing designed for robust performance in various machinery, including agricultural equipment and conveyor systems. Featuring a 40mm bore diameter, an 80mm outer diameter, and a total width of 49.2mm, this bearing insert includes a spherical outer ring and P-seals on both sides for enhanced protection against contaminants. It is secured with grub screws and has a weight of 0.65 kg, ensuring reliable operation with a dynamic load rating of 25.5 kN and a static load rating of 15.3 kN.
INA FAG
INA and FAG are two prominent brands under the Schaeffler Group, a global automotive and industrial supplier based in Herzogenaurach, Germany. FAG was founded in 1883 by Friedrich Fischer in Schweinfurt, Germany, and is recognized as a pioneer in the rolling bearing industry. INA was established in 1946 by Dr. Georg Schaeffler and Dr. Wilhelm Schaeffler in Herzogenaurach. Both brands were acquired by Schaeffler, forming a powerful combination in bearing technology and precision components. The Schaeffler Group, through its INA and FAG brands, offers an extensive portfolio of high-precision components and systems for various industrial applications, including agricultural machinery. FAG is particularly known for its rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, suchers as rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, such as cam followers, tensioner pulleys, and clutch release bearings, as well as specific bearing solutions. Their products are engineered for durability, efficiency, and performance in demanding environments. At Partao, you can find a wide range of genuine INA FAG spare parts across top categories such as Ball Bearings, Air Filters, Axle Seals, Battery Chargers, and Bearing Housings. These components are critical for the smooth operation and longevity of various agricultural machines, from tractors to harvesters, ensuring reliable power transmission and reduced friction. INA FAG components are trusted by agricultural machinery manufacturers and operators worldwide due to their reputation for precision engineering and robust construction. The brands' products are designed to withstand the harsh conditions and heavy loads typical in farming operations, contributing to the overall reliability and efficiency of the equipment. Their global presence and commitment to innovation ensure widespread availability and continuous technological advancement. Shop more than 17,981 genuine INA FAG spare parts.
