INA FAG - RATY25 - Sheet Steel Flanged Bearing Unit

OEM Supplier

SKU: ina-fag-raty25

INA FAG - RATY25 - Sheet Steel Flanged Bearing Unit

€24.09

(excl. VAT)

In stock - ready to ship

Ships within 88 hours

Shipping fee: €6.00 excl. VAT

Pay Securely with

Price

(Excl. VAT)

€24.09

The INA-FAG RATY25 is a high-quality sheet steel flanged bearing unit designed for robust performance in various agricultural and industrial machinery. Featuring a 25mm bore diameter, this unit is built for reliable operation, offering a dynamic load rating of 14.3 kN and a static load rating of 7.8 kN. Its durable sheet steel housing ensures longevity, while the unit's compact design and two-bolt mounting simplify installation. With an operating temperature range of -20 to +120 °C and a limiting speed of 3800 rpm, the RATY25 provides efficient and consistent support.
INA FAG
INA and FAG are two prominent brands under the Schaeffler Group, a global automotive and industrial supplier based in Herzogenaurach, Germany. FAG was founded in 1883 by Friedrich Fischer in Schweinfurt, Germany, and is recognized as a pioneer in the rolling bearing industry. INA was established in 1946 by Dr. Georg Schaeffler and Dr. Wilhelm Schaeffler in Herzogenaurach. Both brands were acquired by Schaeffler, forming a powerful combination in bearing technology and precision components. The Schaeffler Group, through its INA and FAG brands, offers an extensive portfolio of high-precision components and systems for various industrial applications, including agricultural machinery. FAG is particularly known for its rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, suchers as rolling bearings, plain bearings, and linear guidance systems, while INA specializes in engine components, such as cam followers, tensioner pulleys, and clutch release bearings, as well as specific bearing solutions. Their products are engineered for durability, efficiency, and performance in demanding environments. At Partao, you can find a wide range of genuine INA FAG spare parts across top categories such as Ball Bearings, Air Filters, Axle Seals, Battery Chargers, and Bearing Housings. These components are critical for the smooth operation and longevity of various agricultural machines, from tractors to harvesters, ensuring reliable power transmission and reduced friction. Over 1717,174 genuine INA FAG spare parts are available at Partao. INA FAG components are trusted by agricultural machinery manufacturers and operators worldwide due to their reputation for precision engineering and robust construction. The brands' products are designed to withstand the harsh conditions and heavy loads typical in farming operations, contributing to the overall reliability and efficiency of the equipment. Their global presence and commitment to innovation ensure widespread availability and continuous technological advancement.

Brand
Part Numbers
raty25
Unit
Each
Weight
0,25 kg
Properties
Housing components rust-resistant through Corrotect N coating Inner bearing has one-sided extended inner ring with 2 adjusting screws No subsequent lubrication possible
Consists of
2 halves of housing Clamp bearing
Total width
27 mm
Housing type
Oval flange
Total height
21,5 mm
BTotal length
71 mm
AHousing width
95,2 mm
Flange thickness
9,5 mm
KMounting holes length
8,7 mm
Mounting holes distance
76 mm
Basic radial load static
7800 N
dBearing inside diameter
25 mm
Basic radial load dynamic
14000 N
LBearing inner ring width
27 mm
Grease nipple thread diameter
M6
EAN
4012802797114
Manufacturer
INA/FAG
