INA FAG - TSHE30 - Housing Unit Tshe

INA FAG - TSHE30 - Housing Unit Tshe

INA FAG - TSHE30 - Housing Unit Tshe

INA FAG - TSHE30 - Housing Unit Tshe

INA FAG - TSHE30 - Housing Unit Tshe

Number of products

In stock - ready to ship

Order now for delivery between 22 May and 26 May

Free shipping on orders over €60

Pay Securely with

INA FAG - TSHE30 - Housing Unit Tshe

INA FAG - TSHE30 - Housing Unit Tshe

€56.73

(Excl. VAT)

Price

(Excl. VAT)

€56.73

Number of products

INA FAG

Ina-fag is a supplier of precision bearings and components for agricultural machinery. The brand offers high-quality bearings for tractors, harvesters, and other heavy-duty equipment. Ina-fag products are engineered to withstand harsh farming conditions and reduce maintenance needs. Shop more than 17,174 genuine Ina-fag spare parts.

Product Details

Brand

Unit

Each

Weight

0,99 kg

Benefits

Very good protection against contamination Low space requirement

Properties

Inner bearing has extended inner ring with clamp ring on both sides Can be subsequently lubricated

Consists of

• Bearing block Clamp ring

Housing type

Pillow block - short

HTotal height

82 mm

WTotal length

98 mm

BHousing width

40 mm

Flange thickness

9 mm

Bearing inside diameter

30 mm

Mounting holes distance

76,2 mm

AShaft vertical distance

42,9 mm

Mounting thread diameter

M10

LBearing inner ring width

48,5 mm

Grease nipple thread diameter

M6

Locking ring outside diameter

44 mm

OBearing balls distance to mounting surface

30,1 mm

Manufacturer

INA/FAG
